ServerlessWorkflow.Sdk 0.8.0.10

Prefix Reserved

There is a newer version of this package available.
See the version list below for details.

dotnet add package ServerlessWorkflow.Sdk --version 0.8.0.10

NuGet\Install-Package ServerlessWorkflow.Sdk -Version 0.8.0.10

This command is intended to be used within the Package Manager Console in Visual Studio, as it uses the NuGet module's version of Install-Package.

<PackageReference Include="ServerlessWorkflow.Sdk" Version="0.8.0.10" />

For projects that support PackageReference, copy this XML node into the project file to reference the package.

<PackageVersion Include="ServerlessWorkflow.Sdk" Version="0.8.0.10" />


                            Directory.Packages.props

<PackageReference Include="ServerlessWorkflow.Sdk" />


                            Project file

For projects that support Central Package Management (CPM), copy this XML node into the solution Directory.Packages.props file to version the package.

paket add ServerlessWorkflow.Sdk --version 0.8.0.10

The NuGet Team does not provide support for this client. Please contact its maintainers for support.

#r "nuget: ServerlessWorkflow.Sdk, 0.8.0.10"

#r directive can be used in F# Interactive and Polyglot Notebooks. Copy this into the interactive tool or source code of the script to reference the package.

#:package ServerlessWorkflow.Sdk@0.8.0.10

#:package directive can be used in C# file-based apps starting in .NET 10 preview 4. Copy this into a .cs file before any lines of code to reference the package.

#addin nuget:?package=ServerlessWorkflow.Sdk&version=0.8.0.10


                            Install as a Cake Addin

#tool nuget:?package=ServerlessWorkflow.Sdk&version=0.8.0.10


                            Install as a Cake Tool

The NuGet Team does not provide support for this client. Please contact its maintainers for support.

Serverless Workflow Specification - .NET SDK

Provides .NET 6.0 API/SPI and Model Validation for the Serverless Workflow Specification

With the SDK, you can:

Read and write workflow JSON and YAML definitions
Programmatically build workflow definitions
Validate workflow definitions (both schema and DSL integrity validation)

Status

Latest Releases	Conformance to spec version
0.8.0.10	v0.7

Getting Started

dotnet nuget add package ServerlessWorkflow.Sdk

services.AddServerlessWorkflow();

How to use

Building workflows programatically

var workflow = WorkflowDefinition.Create("MyWorkflow", "MyWorkflow", "1.0")
  .StartsWith("inject", flow =>
      flow.Inject(new { username = "test", password = "123456" }))
  .Then("operation", flow =>
      flow.Execute("fakeApiFunctionCall", action =>
      {
          action.Invoke(function =>
              function.WithName("fakeFunction")
                  .SetOperationUri(new Uri("https://fake.com/swagger.json#fake")))
              .WithArgument("username", "${ .username }")
              .WithArgument("password", "${ .password }");
      })
          .Execute("fakeEventTrigger", action =>
          {
               action
                    .Consume(e =>
                        e.WithName("fakeEvent")
                            .WithSource(new Uri("https://fakesource.com"))
                            .WithType("fakeType"))
                    .ThenProduce(e =>
                        e.WithName("otherEvent")
                            .WithSource(new Uri("https://fakesource.com"))
                            .WithType("fakeType"));
          }))
  .End()
  .Build();

Reading workflows

var reader = WorkflowReader.Create();
using(Stream stream = File.OpenRead("myWorkflow.json"))
{
  var definition = reader.Read(stream, WorkflowDefinitionFormat.Json);
}

Writing workflows

  var writer = WorkflowWriter.Create();
  using(Stream stream = new MemoryStream())
  {
      writer.Write(workflow, stream);
      stream.Flush();
      stream.Position = 0;
      using(StreamReader reader = new StreamReader(stream))
      {
          var yaml = reader.ReadToEnd();
          Console.WriteLine(yaml);
          Console.ReadLine();
      }
  }

Validating workflows

var validator = serviceProvider.GetRequiredService<IValidator<WorkflowDefinition>>();
var validationResult = validator.Validate(myWorkflow);

Product	Compatible and additional computed target framework versions.
.NET	net6.0 is compatible. net6.0-android was computed. net6.0-ios was computed. net6.0-maccatalyst was computed. net6.0-macos was computed. net6.0-tvos was computed. net6.0-windows was computed. net7.0 was computed. net7.0-android was computed. net7.0-ios was computed. net7.0-maccatalyst was computed. net7.0-macos was computed. net7.0-tvos was computed. net7.0-windows was computed. net8.0 was computed. net8.0-android was computed. net8.0-browser was computed. net8.0-ios was computed. net8.0-maccatalyst was computed. net8.0-macos was computed. net8.0-tvos was computed. net8.0-windows was computed. net9.0 was computed. net9.0-android was computed. net9.0-browser was computed. net9.0-ios was computed. net9.0-maccatalyst was computed. net9.0-macos was computed. net9.0-tvos was computed. net9.0-windows was computed. net10.0 was computed. net10.0-android was computed. net10.0-browser was computed. net10.0-ios was computed. net10.0-maccatalyst was computed. net10.0-macos was computed. net10.0-tvos was computed. net10.0-windows was computed.

Product

.NET

Compatible target framework(s)

Included target framework(s) (in package)

Learn more about Target Frameworks and .NET Standard.

net6.0
- CloudNative.CloudEvents (>= 2.2.0)
- FluentValidation.DependencyInjectionExtensions (>= 10.3.6)
- Iso8601DurationHelper (>= 1.0.5)
- Microsoft.Extensions.DependencyInjection (>= 6.0.0)
- Microsoft.Extensions.Http (>= 6.0.0)
- Microsoft.Extensions.Options (>= 6.0.0)
- Neuroglia.Serialization.Json (>= 2.0.1.27)
- Neuroglia.Serialization.NewtonsoftJson (>= 2.0.1.27)
- Neuroglia.Serialization.Protobuf (>= 2.0.1.27)
- Neuroglia.Serialization.YamlDotNet (>= 2.0.1.27)
- Newtonsoft.Json (>= 13.0.1)
- Newtonsoft.Json.Schema (>= 3.0.14)
- Octokit (>= 0.50.0)
- protobuf-net.Core (>= 3.0.101)
- YamlDotNet (>= 11.2.1)
