ThingsGatewayRuntime

ThingsGatewayRuntime 是 ThingsGateway 的工业物联网边缘网关运行时，负责设备采集、变量计算、数据转发、历史数据、实时报警、规则引擎和 Web 管理。

项目组成

模块 路径 说明
运行时宿主 src/ThingsGatewayRuntime 配置加载、应用启动和进程入口
应用核心 src/ThingsGatewayRuntime.Application 通道、设备、变量、报警、历史数据、规则引擎和管理 API
驱动基础 src/ThingsGatewayRuntime.Foundation 通信通道、设备抽象、数据转换和驱动基础设施
内置插件 src/ThingsGatewayRuntime.Plugin 可用于常规运行环境的采集与业务插件
非 AOT 插件 src/ThingsGatewayRuntime.NOAOTPlugin OPC 等依赖动态能力的插件
前端资源 src/ThingsGatewayRuntime.Frontend 嵌入运行时的 Web 静态资源
脚本编译器 src/ThingsGatewayScriptCompiler 脚本和表达式编译支持
源生成器 analyzer 表达式和插件注册代码生成
Bootstrapper src/Bootstrapper .NET 10 离线环境检测、安装和应用启动
Web 前端 web Vue 3 网关管理界面
自动化测试 test/ThingsGatewayRuntime.Test 核心运行时、驱动、规则和安全测试

功能特性

  • 通道、设备、变量的统一建模、批量配置、状态监控和在线调试。
  • Modbus、Siemens S7、DL/T 645、MQTT、OPC UA/DA 等内置协议，扩展协议由插件项目提供。
  • 实时数据缓存、变量读写、WebSocket 推送和网关间同步。
  • 历史数据与历史报警查询、实时报警、确认和配置管理。
  • 采集驱动与业务插件生命周期、动态属性和权限元数据。
  • 数据转发到 MQTT、RabbitMQ、Kafka、数据库、HTTP 等目标。
  • 可视化规则流、自定义节点、运行时脚本和表达式。
  • 工程备份恢复、冗余管理、健康检查、日志、审计和 TAdmin 权限体系。

技术栈

技术 当前配置 用途
.NET net10.0 后端运行时和测试
TouchSocket 4.2.17 TCP、UDP、串口、MQTT、WebApi 和 WebSocket
TAdmin 2.1.12 用户、角色、权限、认证和审计
TUtility 2.0.55 应用启动与通用基础能力
TORM 2.0.54 运行时数据库访问
Vue 3.5.x Web 管理界面
TypeScript 6.0.x 前端类型系统
Element Plus 2.14.x 前端组件库
Vite 8.0.x 前端开发和构建

目录结构

ThingsGatewayRuntime/
|-- analyzer/
|   |-- ThingsGatewayRuntime.ExpressionsGenerator/
|   `-- ThingsGatewayRuntime.PluginsGenerator/
|-- src/
|   |-- Bootstrapper/
|   |-- ThingsGatewayRuntime/
|   |-- ThingsGatewayRuntime.Application/
|   |-- ThingsGatewayRuntime.Foundation/
|   |-- ThingsGatewayRuntime.Frontend/
|   |-- ThingsGatewayRuntime.Plugin/
|   |-- ThingsGatewayRuntime.NOAOTFoundation/
|   |-- ThingsGatewayRuntime.NOAOTPlugin/
|   `-- ThingsGatewayScriptCompiler/
|-- test/ThingsGatewayRuntime.Test/
|-- web/
|-- Directory.Build.props
`-- README.md

开发环境

  • .NET SDK 10
  • Node.js 22 和 npm
  • 仓库工作区构建时使用同级 TAdmin、TUtility 和 TORM 源码；单独使用项目时改用对应 NuGet 包。

构建

从 ThingsGateway 目录构建包含 Runtime、PRO 和 Studio 的解决方案：

dotnet restore ThingsGatewayRuntime.slnx
dotnet build ThingsGatewayRuntime.slnx -c Release

只构建运行时：

dotnet build ThingsGatewayRuntime/src/ThingsGatewayRuntime/ThingsGatewayRuntime.csproj -c Release

运行测试：

dotnet test ThingsGatewayRuntime/test/ThingsGatewayRuntime.Test/ThingsGatewayRuntime.Test.csproj -c Release

前端开发

cd web
npm install
npm run dev

开发服务器默认使用 http://localhost:3100。构建生产资源：

npm run check
npm run build

npm run build 会执行类型检查、生成静态资源，并把资源复制到 ThingsGatewayRuntime.Frontend 的嵌入目录。

运行

先构建前端资源，再启动后端：

dotnet run --project src/ThingsGatewayRuntime/ThingsGatewayRuntime.csproj

默认 WebApi 端口为 6100。运行目录下的 Configuration 用于数据库、JWT、OAuth2、日志、历史查询和 WebApi 配置；默认 SQLite 连接启用 WAL 日志模式。

扩展开发

相关资源

  • 官方文档：https://runtime.thingsgateway.cn/
  • Gitee：https://gitee.com/diego2098/ThingsGateway
  • GitHub：https://github.com/kimdiego2098/ThingsGateway
  • QQ 群：605534569

许可证

本项目使用 Apache-2.0 协议。
