S3Server 8.0.1

S3Server

S3Server is a lightweight, high-performance .NET library that provides a server-side interface for building Amazon S3-compatible storage services. It parses incoming S3 HTTP requests and routes them to your callback implementations, allowing you to focus on storage logic rather than protocol details.

What is S3Server?

S3Server is a protocol adapter that handles the complexity of the Amazon S3 REST API, allowing you to build S3-compatible storage servers without dealing with HTTP parsing, XML serialization, signature validation, or AWS-specific request routing.

What S3Server does:

• Parses incoming S3 HTTP requests
• Determines request type (service, bucket, or object operations)
• Validates AWS Signature V4 and optional legacy Signature V2
• Supports opt-in anonymous public access decisions
• Deserializes XML request bodies
• Routes requests to your callback methods
• Serializes response objects to XML
• Emits archive restore headers from object restore state
• Handles error responses with proper S3 error codes

What S3Server does NOT do:

• Store objects or buckets (you implement storage in your callbacks)
• Store users, credentials, ACLs, or policies (you control access data in your application)
• Manage metadata persistence (you handle metadata storage)

Want a complete S3-compatible storage server built using S3Server? Check out Less3.

Why Use S3Server?

• S3 API Compatibility: Build services that work with existing S3 clients (AWS SDK, CLI, MinIO client, etc.)
• Focus on Storage Logic: Spend your time implementing storage, not parsing HTTP requests
• Flexible Architecture: Complete control over where and how you store data
• Multi-Framework Support: Targets .NET 8.0 and .NET 10.0
• Production Ready: Handles path-style and virtual-hosted-style URLs, signature validation, multipart uploads, and more

Use Cases

• Custom S3-compatible storage backends: Build object storage on top of databases, file systems, cloud storage, or distributed systems
• S3 gateway services: Create proxies or gateways that translate S3 requests to other storage protocols
• Testing and development: Build mock S3 servers for testing applications without AWS dependencies
• Compliance and data residency: Keep complete control over data location and access patterns
• Feature extension: Add custom logic, caching, encryption, or auditing to S3 operations
• Cost optimization: Implement tiered storage or custom retention policies
• Air-gapped environments: Deploy S3-compatible storage in isolated networks

Features

✅ Complete S3 API Coverage

• Service operations (list buckets, check service)
• Bucket operations (CRUD, ACLs, tags, versioning, website config, logging, location)
• Object operations (CRUD, ACLs, tags, legal hold, retention, range reads, archive restore)
• Multipart upload support (initiate, upload parts, complete, abort, list parts)
• S3 Select API support

✅ URL Style Support

• Path-style URLs: http://host:port/bucket/key (default)
• Virtual-hosted-style URLs: http://bucket.domain/key (configurable)

✅ Security & Validation

• AWS Signature V4 validation, plus opt-in legacy Signature V2 validation
• Opt-in anonymous authorization hook for public-read/public-write compatibility
• Pre-request hooks for custom validation
• Post-request hooks for logging and metrics

✅ Developer Friendly

• Strongly-typed request/response objects
• Comprehensive error handling with S3-compliant error codes
• Detailed logging support
• Configurable operation limits

Quick Start

Installation

dotnet add package S3Server

Basic Example

using S3ServerLibrary;
using S3ServerLibrary.S3Objects;

namespace S3ServerLibrary
{
    using System;
    using System.Threading.Tasks;
    using WatsonWebserver.Core;

    // Configure server settings
    S3ServerSettings settings = new S3ServerSettings();
    settings.Webserver = new WebserverSettings("localhost", 8000, false);
    settings.Logger = Console.WriteLine;

    // Create and configure server
    S3Server server = new S3Server(settings);

    // Wire up callbacks
    server.Service.ListBuckets = async (ctx) =>
    {
        ListAllMyBucketsResult result = new ListAllMyBucketsResult();
        result.Owner = new Owner("admin", "Administrator");
        result.Buckets = new Buckets(new List<Bucket>
        {
            new Bucket("my-bucket", DateTime.UtcNow)
        });
        return result;
    };

    server.Bucket.Exists = async (ctx) =>
    {
        // Check if bucket exists in your storage
        return true;
    };

    server.Object.Write = async (ctx) =>
    {
        // Save object data from ctx.Request.Data stream
        Console.WriteLine($"Writing object: {ctx.Request.Bucket}/{ctx.Request.Key}");
        Console.WriteLine($"Content length: {ctx.Request.ContentLength}");
        // Implement your storage logic here
    };

    server.Object.Read = async (ctx) =>
    {
        // Retrieve object from your storage
        byte[] data = System.Text.Encoding.UTF8.GetBytes("Hello, S3!");
        return new S3Object(
            ctx.Request.Key,
            "version-1",
            true,
            DateTime.UtcNow,
            "etag-123",
            data.Length,
            new Owner("admin", "Administrator"),
            data,
            "text/plain",
            StorageClassEnum.STANDARD
        );
    };

    // Start server
    server.Start();
    Console.WriteLine("S3 Server listening on http://localhost:8000");
}

Configuration

Server Settings

S3ServerSettings settings = new S3ServerSettings
{
    // Required: Webserver configuration
    Webserver = new WebserverSettings("localhost", 8000, false),

    // Optional: Logger for diagnostic output
    Logger = (msg) => Console.WriteLine(msg),

    // Optional: Enable specific logging categories
    Logging = new LoggingSettings
    {
        HttpRequests = true,
        S3Requests = true,
        SignatureV4Validation = false
    },

    // Optional: Operation limits
    OperationLimits = new OperationLimitsSettings
    {
        MaxPutObjectSize = 5368709120 // 5GB default
    },

    // Optional: Enable AWS Signature V4 validation
    EnableSignatures = false,

    // Optional: Enable legacy AWS Signature V2 validation when signatures are enabled
    EnableSignatureV2 = false,

    // Optional: Validate signatures before PreRequestHandler runs (default false)
    ValidateSignaturesBeforePreRequestHandler = false,

    // Optional: Route suffix ranges (bytes=-N) to Object.ReadRange (default true)
    RouteSuffixRangesToReadRange = true,

    // Optional: Keep the webserver's default Host, Accept, Accept-Language, Accept-Charset,
    // Cache-Control, and CORS response headers on every response (default false, which removes them)
    PreserveWebserverDefaultHeaders = false,

    // Optional: Send the webserver's CORS (Access-Control-*) headers on responses to requests
    // that carry an Origin header, for browser-based clients (default false, as Amazon S3 does
    // for a bucket without a CORS configuration)
    EmitCorsHeaders = false,

    // Note: UseTcpServer is deprecated in v7.0; Watson now uses TCP natively
    UseTcpServer = false
};

Request Handlers

S3Server provides hooks to intercept requests at different stages. The order is:

PreRequestHandler -> signature validation -> AuthenticatedRequestHandler -> operation callback -> PostRequestHandler

With ValidateSignaturesBeforePreRequestHandler = true, signature validation moves ahead of PreRequestHandler.

Security: with the default order, PreRequestHandler runs before signature validation and sees unauthenticated input. Use it for logging, metrics, or populating ctx.Metadata for Service.GetSecretKey. Do not answer, modify, or disclose data from it. Anything that answers requests belongs in AuthenticatedRequestHandler, which only runs for requests that passed signature validation (or were allowed by Service.IsAnonymousRequestAllowed).

// Pre-request handler (logging, metadata for GetSecretKey)
// Sees unauthenticated input under the default order.
// Return true to terminate request, false to continue routing
settings.PreRequestHandler = async (ctx) =>
{
    // Add custom metadata for downstream callbacks
    ctx.Metadata = new { TenantId = LookupTenant(ctx.Request.AccessKey) };

    return false; // Continue to signature validation and routing
};

// Authenticated request handler (authorization, request interception)
// Only invoked after signature validation succeeds.
// Return true to terminate request, false to continue routing
settings.AuthenticatedRequestHandler = async (ctx) =>
{
    if (!IsAuthorized(ctx))
    {
        await ctx.Response.Send(ErrorCode.AccessDenied);
        return true; // Terminate
    }

    return false; // Continue to callback routing
};

// Default request handler (called when no callback matches)
settings.DefaultRequestHandler = async (ctx) =>
{
    Console.WriteLine($"Unhandled request: {ctx.Request.RequestType}");
    await ctx.Response.Send(ErrorCode.InvalidRequest);
};

// Post-request handler (logging, metrics)
settings.PostRequestHandler = async (ctx) =>
{
    Console.WriteLine($"Completed: {ctx.Request.RequestType} - {ctx.Response.StatusCode}");
    // Log metrics, update statistics, etc.
};

AWS Signature Validation

Enable AWS signature validation for authenticated requests. Signature V4 is enabled by EnableSignatures; legacy Signature V2 remains disabled unless EnableSignatureV2 is also set.

settings.EnableSignatures = true;
settings.EnableSignatureV2 = false; // Set true only for legacy S3-compatible clients
settings.Logging.SignatureV4Validation = true; // Optional debug logging

// Implement callback to retrieve secret key for access key
server.Service.GetSecretKey = (ctx) =>
{
    string accessKey = ctx.Request.AccessKey;

    // Look up and return the secret key for this access key
    return "wJalrXUtnFEMI/K7MDENG/bPxRfiCYEXAMPLEKEY";

    // Or throw exception if access key is invalid
    // throw new S3Exception(new Error(ErrorCode.InvalidAccessKeyId));
};

When EnableSignatureV2 is true, S3Server validates legacy V2 header signatures such as Authorization: AWS AWSAccessKeyId:Signature and V2 signed URLs containing AWSAccessKeyId, Expires, and Signature. Expired V2 signed URLs are rejected. V2 support is intended for compatibility with older S3 clients and S3-compatible storage ecosystems; AWS has deprecated Signature V2, so leave it disabled unless you need that legacy behavior.

Anonymous Public Access

When signature validation is enabled, unsigned requests are rejected by default. To support S3-compatible public-read or public-write behavior, set Service.IsAnonymousRequestAllowed. S3Server calls this callback only for requests that do not include an Authorization header, V2 signed URL parameters, or recognized V4 presigned URL material. Requests that include signature material still validate normally and fail closed if the signature is invalid.

settings.EnableSignatures = true;

server.Service.GetSecretKey = (ctx) =>
{
    return LookupSecretKey(ctx.Request.AccessKey);
};

server.Service.IsAnonymousRequestAllowed = async (ctx) =>
{
    // Example: consult your bucket/object ACL store for the AllUsers group.
    switch (ctx.Request.PermissionsRequired)
    {
        case S3PermissionType.ObjectRead:
        case S3PermissionType.BucketRead:
            return await GrantsPublicRead(ctx.Request.Bucket, ctx.Request.Key);

        case S3PermissionType.BucketWrite:
            return await GrantsPublicWrite(ctx.Request.Bucket);

        default:
            return false;
    }
};

Keep the callback narrow. For example, a public-read object should allow ObjectRead, not ACL writes or administrative operations. A request carrying a bad signature should remain rejected rather than falling back to anonymous access.

Virtual-Hosted-Style URLs

Support bucket names in hostnames (http://bucket.s3.local/key instead of http://s3.local/bucket/key):

// 1. Use wildcard listener (requires admin privileges on Windows)
settings.Webserver.Hostname = "*"; // or "+" or "0.0.0.0"

// 2. Implement base domain finder
server.Service.FindMatchingBaseDomain = (hostname) =>
{
    // Input: "mybucket.s3.local.gd"
    // Output: "s3.local.gd" (the base domain)

    if (hostname.EndsWith(".s3.local.gd"))
        return "s3.local.gd";

    if (hostname.EndsWith(".s3.example.com"))
        return "s3.example.com";

    // No match found - will be treated as path-style
    throw new KeyNotFoundException($"No base domain for {hostname}");
};

DNS Configuration:

• Configure DNS or hosts file to resolve bucket subdomains
• For local testing: *.local.gd and *.fbi.com resolve to localhost
• Example: mybucket.s3.local.gd → 127.0.0.1

Callback Implementation Patterns

Pattern 1: Return Typed Result

server.Bucket.ReadAcl = async (ctx) =>
{
    AccessControlList acl = new AccessControlList(
        new List<Grant>
        {
            new Grant(
                new Grantee("admin", "Administrator", null, "CanonicalUser", "admin@example.com"),
                PermissionEnum.FullControl
            )
        }
    );

    return new AccessControlPolicy(
        new Owner("admin", "Administrator"),
        acl
    );
};

Pattern 2: Return Void (No Response Body)

server.Bucket.Delete = async (ctx) =>
{
    string bucketName = ctx.Request.Bucket;

    // Delete bucket from your storage
    DeleteBucketFromStorage(bucketName);

    // Return normally - S3Server sends 204 No Content
    return;
};

Pattern 3: Throw S3Exception on Error

server.Bucket.Exists = async (ctx) =>
{
    if (!BucketExistsInStorage(ctx.Request.Bucket))
    {
        throw new S3Exception(new Error(ErrorCode.NoSuchBucket));
    }

    return true;
};

Pattern 4: Using Metadata for Context

// Set metadata in PreRequestHandler
settings.PreRequestHandler = async (ctx) =>
{
    ctx.Metadata = new { TenantId = GetTenantFromAuth(ctx) };
    return false;
};

// Access metadata in callbacks
server.Object.Write = async (ctx) =>
{
    dynamic metadata = ctx.Metadata;
    string tenantId = metadata.TenantId;

    // Use tenant context for multi-tenant storage
    SaveObject(tenantId, ctx.Request.Bucket, ctx.Request.Key, ctx.Request.Data);
};

Complete API Reference

Service Callbacks

Callback	Description	Method	URL	Response Type
Service.ListBuckets	List all buckets	GET	/	ListAllMyBucketsResult
Service.ServiceExists	Check service and return region	HEAD	/	string (region)
Service.FindMatchingBaseDomain	Find base domain for virtual hosting	N/A	N/A	string (base domain)
Service.GetSecretKey	Get secret key for access key (auth)	N/A	N/A	string (secret key)
Service.IsAnonymousRequestAllowed	Allow selected unsigned anonymous requests	N/A	N/A	bool

Bucket Callbacks

Callback	Description	Method	URL	Response Type
Bucket.Write	Create a bucket	PUT	/[bucket]	void
Bucket.Read	List objects in bucket	GET	/[bucket]	ListBucketResult
Bucket.Exists	Check if bucket exists	HEAD	/[bucket]	bool
Bucket.Delete	Delete a bucket	DELETE	/[bucket]	void
Bucket.ReadAcl	Read bucket ACL	GET	/[bucket]?acl	AccessControlPolicy
Bucket.WriteAcl	Write bucket ACL (policy is null for canned ACLs)	PUT	/[bucket]?acl	void
Bucket.DeleteAcl	Delete bucket ACL	DELETE	/[bucket]?acl	void
Bucket.ReadLocation	Get bucket region	GET	/[bucket]?location	LocationConstraint
Bucket.ReadLogging	Get logging config	GET	/[bucket]?logging	BucketLoggingStatus
Bucket.WriteLogging	Set logging config	PUT	/[bucket]?logging	void
Bucket.ReadTagging	Get bucket tags	GET	/[bucket]?tagging	Tagging
Bucket.WriteTagging	Set bucket tags	PUT	/[bucket]?tagging	void
Bucket.DeleteTagging	Delete bucket tags	DELETE	/[bucket]?tagging	void
Bucket.ReadVersioning	Get versioning config	GET	/[bucket]?versioning	VersioningConfiguration
Bucket.WriteVersioning	Set versioning config	PUT	/[bucket]?versioning	void
Bucket.ReadVersions	List object versions	GET	/[bucket]?versions	ListVersionsResult
Bucket.ReadWebsite	Get website config	GET	/[bucket]?website	WebsiteConfiguration
Bucket.WriteWebsite	Set website config	PUT	/[bucket]?website	void
Bucket.DeleteWebsite	Delete website config	DELETE	/[bucket]?website	void
Bucket.ReadMultipartUploads	List multipart uploads	GET	/[bucket]?uploads	ListMultipartUploadsResult

Object Callbacks

Callback	Description	Method	URL	Response Type
Object.Write	Upload object	PUT	/[bucket]/[key]	void
Object.Copy	Copy object	PUT	/[bucket]/[key] with x-amz-copy-source	CopyObjectResult
Object.Read	Download object	GET	/[bucket]/[key]	S3Object
Object.Exists	Check if object exists	HEAD	/[bucket]/[key]	ObjectMetadata
Object.Delete	Delete object	DELETE	/[bucket]/[key]	void
Object.ReadRange	Download byte range	GET	/[bucket]/[key]*	S3Object
Object.ReadAcl	Get object ACL	GET	/[bucket]/[key]?acl	AccessControlPolicy
Object.WriteAcl	Set object ACL (policy is null for canned ACLs)	PUT	/[bucket]/[key]?acl	void
Object.DeleteAcl	Delete object ACL	DELETE	/[bucket]/[key]?acl	void
Object.ReadTagging	Get object tags	GET	/[bucket]/[key]?tagging	Tagging
Object.WriteTagging	Set object tags	PUT	/[bucket]/[key]?tagging	void
Object.DeleteTagging	Delete object tags	DELETE	/[bucket]/[key]?tagging	void
Object.ReadLegalHold	Get legal hold status	GET	/[bucket]/[key]?legal-hold	LegalHold
Object.WriteLegalHold	Set legal hold status	PUT	/[bucket]/[key]?legal-hold	void
Object.ReadRetention	Get retention status	GET	/[bucket]/[key]?retention	Retention
Object.WriteRetention	Set retention status	PUT	/[bucket]/[key]?retention	void
Object.DeleteMultiple	Delete multiple objects	POST	/[bucket]?delete	DeleteResult
Object.Restore	Restore archived object	POST	/[bucket]/[key]?restore	RestoreObjectResult
Object.SelectContent	S3 Select query	POST	/[bucket]/[key]?select&select-type=2	void

* ReadRange is triggered when a valid single-range Range header is present. A Range header that cannot be parsed (multiple ranges, a unit other than bytes, non-numeric bounds, or last < first) is ignored, as Amazon S3 does, and the request is served by Object.Read with 200.

In a ReadRange callback, set S3Object.Size to the number of bytes in the returned range and S3Object.TotalSize to the full object size. S3Server then emits Content-Range: bytes start-end/total on the 206 Partial Content response; ranged/multipart download clients (for example the AWS CLI) require this numeric total. If TotalSize is left null, the total is emitted as * (unknown).

For a suffix range (Range: bytes=-N, the last N bytes), RangeStart and RangeEnd are null and ctx.Request.RangeSuffixLength is set. Return the last N bytes (or the whole object if it is shorter) and set TotalSize, which is required: S3Server computes Content-Range from it, and fails the request with InternalError if it is missing. Set RouteSuffixRangesToReadRange = false to send suffix ranges to Object.Read as versions before 7.4.0 did.

When TotalSize is set, S3Server applies Amazon S3's range rules itself, so a ReadRange callback can simply clamp and return what it has:

• A range that starts at or past the end of the object (bytes=10- on a 10-byte object) and a zero-length suffix (bytes=-0) return 416 InvalidRange with RangeRequested and ActualObjectSize in the error body.
• A suffix range on an empty object returns 200 with an empty body.
• Content-Range describes the bytes actually returned, so bytes=0-100 on a 10-byte object is answered with bytes 0-9/10.

HEAD honors Range the same way: 206 with Content-Range and the length of the range, or 416.

Object.WriteAcl and Bucket.WriteAcl receive a null policy when the request has no body, which is how canned ACLs (x-amz-acl) and grant headers (x-amz-grant-*) arrive. Read those headers with ctx.Request.RetrieveHeaderValue. A body that is present but not valid XML is rejected with MalformedACLError, as Amazon S3 does.

Object.Copy receives a PUT carrying x-amz-copy-source. The source is parsed into ctx.Request.CopySourceBucket, CopySourceKey, and CopySourceVersionId. If Object.Copy is not set, the request goes to DefaultRequestHandler or returns NotImplemented. It is never delivered to Object.Write.

For archived objects, set ObjectMetadata.RestoreStatus and S3Object.RestoreStatus to have S3Server emit the x-amz-restore response header on HEAD and GET.

Multipart Upload Callbacks

Callback	Description	Method	URL	Response Type
Object.CreateMultipartUpload	Initiate multipart upload	POST	/[bucket]/[key]?uploads	InitiateMultipartUploadResult
Object.UploadPart	Upload a part	PUT	/[bucket]/[key]?partNumber=N&uploadId=ID	void
Object.UploadPartCopy	Upload a part by copying	PUT	/[bucket]/[key]?partNumber=N&uploadId=ID with x-amz-copy-source	CopyPartResult
Object.ReadParts	List uploaded parts	GET	/[bucket]/[key]?uploadId=ID	ListPartsResult
Object.CompleteMultipartUpload	Complete upload	POST	/[bucket]/[key]?uploadId=ID	CompleteMultipartUploadResult
Object.AbortMultipartUpload	Abort upload	DELETE	/[bucket]/[key]?uploadId=ID	void

Request and Response Objects

S3Context

The S3Context object is passed to all callbacks:

public class S3Context
{
    // Parsed S3 request details
    public S3Request Request { get; }

    // Response builder
    public S3Response Response { get; }

    // Underlying HTTP context (WatsonWebserver)
    public HttpContextBase Http { get; }

    // User-defined metadata (set in PreRequestHandler)
    public object Metadata { get; set; }

    // Timestamp information
    public Timestamp Timestamp { get; }
}

S3Request

Key properties available in S3Context.Request:

// Request identification
string RequestId              // Unique request ID
string TraceId                // Trace ID for debugging

// Request type and style
S3RequestType RequestType     // Enum: ServiceExists, BucketWrite, ObjectRead, etc.
S3RequestStyle RequestStyle   // PathStyle or VirtualHostedStyle

// S3 resource identifiers
string Bucket                 // Bucket name
string Key                    // Object key
string VersionId              // Version ID (if versioning enabled)

// Authentication
string AccessKey              // AWS access key
string Signature              // Request signature
S3SignatureVersion SignatureVersion // Version2, Version4, or Unknown

// Content details
long ContentLength            // Request body size
string ContentType            // Content type
Stream Data                   // Request body stream
string DataAsString           // Request body as string (fully reads stream)
byte[] DataAsBytes            // Request body as bytes (fully reads stream)

// Range requests
long? RangeStart              // Start byte for range request
long? RangeEnd                // End byte for range request
long? RangeSuffixLength       // N for a suffix range (bytes=-N); RangeStart and RangeEnd are then null

// Copy requests (ObjectCopy and ObjectUploadPartCopy)
string CopySourceBucket       // From x-amz-copy-source, URL-decoded
string CopySourceKey          // From x-amz-copy-source, URL-decoded
string CopySourceVersionId    // From the versionId parameter of x-amz-copy-source
long? CopySourceRangeStart    // From x-amz-copy-source-range
long? CopySourceRangeEnd      // From x-amz-copy-source-range

// Conditional requests (evaluated by your callback; see the property docs for RFC 9110 order)
List<string> IfMatch          // Entity tags as sent, or "*"
List<string> IfNoneMatch      // Entity tags as sent, or "*"
DateTime? IfModifiedSince     // Null when absent or not a valid HTTP date
DateTime? IfUnmodifiedSince   // Null when absent or not a valid HTTP date
// Also CopySourceIfMatch, CopySourceIfNoneMatch, CopySourceIfModifiedSince, CopySourceIfUnmodifiedSince

// Listing parameters
int MaxKeys                   // Maximum keys to return (default 1000)
string Prefix                 // Object key prefix filter
string Delimiter              // Delimiter for grouping
string Marker                 // Pagination marker
string ContinuationToken      // Continuation token for v2 listing
string StartAfter             // start-after for v2 listing
bool FetchOwner               // fetch-owner=true for v2 listing

// Multipart upload
string UploadId               // Multipart upload ID
int PartNumber                // Part number for multipart upload
int MaxParts                  // Maximum parts to return

// Permissions
S3PermissionType PermissionsRequired // Permission needed for this operation

// Helper methods
bool HeaderExists(string key)
bool QuerystringExists(string key)
string RetrieveHeaderValue(string key)
string RetrieveQueryValue(string key)   // URL-decoded value, or null if absent
Task<Chunk> ReadChunk()       // Read chunk for chunked transfer encoding

Use RetrieveQueryValue for querystring parameters S3Server does not parse. It returns decoded values (a%2Fb%20c becomes a/b c). ctx.Http.Request.Query.Elements holds the raw, percent-encoded values.

Querystring parameters are validated only by the operations that use them, with the error Amazon S3 returns (400 InvalidArgument with ArgumentName and ArgumentValue), before any handler runs:

Parameter	Operations	Rejected values
max-keys	ListObjects, ListObjectsV2, ListObjectVersions	negative, non-integer, out of range
max-uploads	ListMultipartUploads	negative, non-integer, out of range
max-parts, part-number-marker	ListParts	negative, non-integer, out of range
partNumber	GetObject, HeadObject, UploadPart, UploadPartCopy	anything other than 1 to 10000
encoding-type	the listing operations	anything other than url

Other operations ignore these parameters, as Amazon S3 does (for example, GET /bucket/key?max-keys=abc returns the object). The error is also available to handlers as ctx.Request.ValidationError.

ctx.Request also parses KeyMarker, VersionIdMarker, UploadIdMarker, MaxUploads, and EncodingType. PartNumberMarker defaults to 0, as Amazon S3's does.

S3Response

Methods for sending responses:

// Send empty response
await ctx.Response.Send();

// Send string response
await ctx.Response.Send("response data");

// Send byte array response
await ctx.Response.Send(bytes);

// Send stream response
await ctx.Response.Send(contentLength, stream);

// Send error response
await ctx.Response.Send(ErrorCode.NoSuchBucket);
await ctx.Response.Send(new Error(ErrorCode.AccessDenied));

// Chunked transfer encoding
await ctx.Response.SendChunk(chunkData, isFinal);

// Set response properties before sending
ctx.Response.StatusCode = 200;
ctx.Response.ContentType = "application/json";
ctx.Response.ContentLength = data.Length;
ctx.Response.Headers.Add("X-Custom-Header", "value");

Error Handling

S3Server provides comprehensive error handling with S3-compliant error codes:

server.Object.Read = async (ctx) =>
{
    if (!ObjectExists(ctx.Request.Key))
    {
        throw new S3Exception(new Error(ErrorCode.NoSuchKey));
    }

    if (!HasPermission(ctx, ctx.Request.Key))
    {
        throw new S3Exception(new Error(ErrorCode.AccessDenied));
    }

    // ... return object
};

Common error codes:

• ErrorCode.NoSuchBucket - 404
• ErrorCode.NoSuchKey - 404
• ErrorCode.AccessDenied - 403
• ErrorCode.BucketAlreadyExists - 409
• ErrorCode.BucketNotEmpty - 409
• ErrorCode.EntityTooLarge - 400
• ErrorCode.InvalidBucketName - 400
• ErrorCode.InternalError - 500
• ErrorCode.SignatureDoesNotMatch - 403

See S3Objects/ErrorCode.cs for the complete list of 60+ error codes.

Conditional Requests (304 Not Modified)

S3Server parses If-Match, If-None-Match, If-Modified-Since, and If-Unmodified-Since into ctx.Request. Your callback decides whether each condition holds, because only it knows the object's ETag and modification time. To answer 304 Not Modified, add the ETag (and optionally Last-Modified) headers and throw NotModified. The response is sent with headers only, with no body and no Content-Type, as Amazon S3 does:

server.Object.Read = async (ctx) =>
{
    ObjectMetadata md = GetMetadata(ctx.Request.Key);
    ctx.Response.Headers.Add("ETag", md.ETag);

    if (ctx.Request.IfNoneMatch != null && ctx.Request.IfNoneMatch.Contains(md.ETag))
        throw new S3Exception(new Error(ErrorCode.NotModified));

    // ... return object
};

A failed If-Match or If-Unmodified-Since should throw PreconditionFailed (412).

Response Format

S3Server shapes response bodies the way Amazon S3 does, so callbacks can return plain models:

• Namespace. Response bodies are serialized in the Amazon S3 namespace (http://s3.amazonaws.com/doc/2006-03-01/). A top-level Error has no namespace, and BucketLoggingStatus uses http://doc.s3.amazonaws.com/2006-03-01. Request bodies are accepted with or without a namespace.
• Timestamps. LastModified, Initiated, CreationDate, and RetainUntilDate are written in UTC with exactly three fractional digits (2026-01-02T03:04:05.000Z).
• ListObjects v1 and v2. A v1 response always has Marker (empty when not set) and never KeyCount, ContinuationToken, StartAfter, or NextContinuationToken. A v2 response never has Marker or NextMarker, and omits Owner from each object unless the request set fetch-owner=true.
• encoding-type=url. When a listing request asks for it (the AWS CLI and boto3 always do), S3Server URL-encodes Key, Prefix, Delimiter, Marker, NextMarker, StartAfter, KeyMarker, and NextKeyMarker the way Amazon S3 does, and sets EncodingType to url. If a callback already set EncodingType on its result, S3Server assumes the callback encoded the values itself and leaves them alone.
• DeleteObjects quiet mode. When the request sets <Quiet>true</Quiet>, Deleted entries are omitted and only errors are returned.
• Error details. Error carries ArgumentName, ArgumentValue, Condition, RangeRequested, ActualObjectSize, UploadId, and BucketName, each written only when set. S3Server fills Key for NoSuchKey, BucketName for NoSuchBucket, UploadId for NoSuchUpload, and RangeRequested for InvalidRange from the request. Set Condition (for example If-Match) when throwing PreconditionFailed.
• HEAD errors. An error response to HEAD has a status and headers but no body.
• Headers. Responses carry no request-only or CORS headers by default; see PreserveWebserverDefaultHeaders and EmitCorsHeaders. Connection: close is sent only when the webserver's keep-alive is disabled (WebserverSettings.IO.EnableKeepAlive, which is off by default).

Serializing a model directly with SerializationHelper.SerializeXml (outside a request) keeps the model's own shape: nothing is omitted or encoded based on a request.

Client Configuration

Use the AWS SDK to connect to your S3Server instance:

using Amazon;
using Amazon.Runtime;
using Amazon.S3;
using Amazon.S3.Model;

BasicAWSCredentials cred = new BasicAWSCredentials("access-key", "secret-key");

AmazonS3Config config = new AmazonS3Config
{
    ServiceURL = "http://localhost:8000/",

    // Use path-style URLs (bucket in path, not hostname)
    ForcePathStyle = true,

    // Or use virtual-hosted-style URLs
    // ForcePathStyle = false,

    UseHttp = true,

    // Optional: Set region
    AuthenticationRegion = "us-west-1"
};

IAmazonS3 client = new AmazonS3Client(cred, config);

// Use client
await client.PutBucketAsync("my-bucket");
await client.PutObjectAsync(new PutObjectRequest
{
    BucketName = "my-bucket",
    Key = "test.txt",
    ContentBody = "Hello, S3!"
});

Advanced Topics

Chunked Transfer Encoding

Handle chunked uploads (e.g., AWS CLI streaming uploads):

server.Object.Write = async (ctx) =>
{
    if (ctx.Request.Chunked)
    {
        List<byte[]> chunks = new List<byte[]>();

        while (true)
        {
            Chunk chunk = await ctx.Request.ReadChunk();

            if (chunk.Length > 0)
            {
                chunks.Add(chunk.Data);
            }

            if (chunk.IsFinal)
                break;
        }

        byte[] completeData = CombineChunks(chunks);
        SaveObject(ctx.Request.Bucket, ctx.Request.Key, completeData);
    }
    else
    {
        // Non-chunked upload
        SaveObject(ctx.Request.Bucket, ctx.Request.Key, ctx.Request.DataAsBytes);
    }
};

Multipart Upload Implementation

// 1. Initiate
server.Object.CreateMultipartUpload = async (ctx) =>
{
    string uploadId = Guid.NewGuid().ToString();

    // Store upload metadata
    StoreUploadMetadata(ctx.Request.Bucket, ctx.Request.Key, uploadId);

    return new InitiateMultipartUploadResult(
        ctx.Request.Bucket,
        ctx.Request.Key,
        uploadId
    );
};

// 2. Upload parts
server.Object.UploadPart = async (ctx) =>
{
    string uploadId = ctx.Request.UploadId;
    int partNumber = ctx.Request.PartNumber;

    // Store part data
    StorePart(uploadId, partNumber, ctx.Request.DataAsBytes);

    // Set ETag header for part
    string etag = CalculateETag(ctx.Request.DataAsBytes);
    ctx.Response.Headers.Add("ETag", etag);
};

// 3. Complete
server.Object.CompleteMultipartUpload = async (ctx, request) =>
{
    // Combine parts in order
    byte[] finalData = CombineParts(ctx.Request.UploadId, request.Parts);

    // Save final object
    SaveObject(ctx.Request.Bucket, ctx.Request.Key, finalData);

    // Clean up parts
    CleanupUpload(ctx.Request.UploadId);

    return new CompleteMultipartUploadResult
    {
        Location = $"http://localhost:8000/{ctx.Request.Bucket}/{ctx.Request.Key}",
        Bucket = ctx.Request.Bucket,
        Key = ctx.Request.Key,
        ETag = CalculateETag(finalData)
    };
};

Archived Object Restore

server.Object.Restore = async (ctx, request) =>
{
    // Start restore work in your backend, or extend an existing restore window.
    bool alreadyRestored = TryExtendRestoreWindow(
        ctx.Request.Bucket,
        ctx.Request.Key,
        request.Days.Value,
        request.EffectiveTier);

    return new RestoreObjectResult
    {
        AlreadyRestored = alreadyRestored
    };
};

server.Object.Exists = async (ctx) =>
{
    return new ObjectMetadata(ctx.Request.Key, DateTime.UtcNow, "etag", 123, new Owner("admin", "Administrator"), StorageClassEnum.GLACIER)
    {
        ContentType = "application/octet-stream",
        RestoreStatus = new RestoreStatus
        {
            OngoingRequest = false,
            ExpiryDate = DateTime.UtcNow.AddDays(7)
        }
    };
};

server.Object.Read = async (ctx) =>
{
    if (!IsRestored(ctx.Request.Bucket, ctx.Request.Key))
        throw new S3Exception(new Error(ErrorCode.InvalidObjectState));

    return new S3Object(ctx.Request.Key, "1", true, DateTime.UtcNow, "etag", 5, new Owner("admin", "Administrator"), "hello", "text/plain", StorageClassEnum.GLACIER)
    {
        RestoreStatus = new RestoreStatus
        {
            OngoingRequest = false,
            ExpiryDate = DateTime.UtcNow.AddDays(7)
        }
    };
};

S3Server routes POST ?restore, returns 202 Accepted for a newly initiated restore, 200 OK when your callback reports an already-restored object, and surfaces restore state through the x-amz-restore header on HEAD and GET.

Operation Limits

Control maximum upload sizes:

settings.OperationLimits = new OperationLimitsSettings
{
    // Maximum size for single PutObject (default 5GB)
    MaxPutObjectSize = 5368709120
};

When exceeded, S3Server automatically returns EntityTooLarge error.

Note: Multipart upload parts are not subject to this limit individually.

Known Limitations

• Chunk signature validation: Not yet supported for chunked transfer encoding with AWS Signature V4
• Behavior that depends on stored data is left to callbacks: for example, GET /bucket/key?partNumber=N on a multipart object (Amazon S3 returns that part with 206 and x-amz-mp-parts-count), versioning semantics, and bucket CORS configurations

The following S3 operations are not exposed through callbacks (may be added in future releases):

Bucket operations:

• Accelerate, Analytics, CORS, Encryption, Inventory, Lifecycle, Notification, Object lock configuration, Policy status, Public access block, Metrics, Payment, Policy, Replication

Object operations:

• Torrent

Examples and Testing

Comprehensive examples are available in the repository:

• Test.Server: Complete server implementation with all callbacks
• Test.Client: S3 client examples using AWS SDK
• Test.RequestStyle: Manual path-style vs virtual-hosted-style URL example harness
• Test.SignatureValidation: Manual AWS Signature V4 and V2 validation example harness
• Test.Automated: Touchstone console runner over the shared suites
• Test.Shared: Touchstone descriptor source of truth for automated, xUnit, and NUnit tests, including parser/routing, compatibility, adversarial, fuzz, lifecycle, and signature coverage
• Test.Xunit: xUnit test project using Touchstone.XunitAdapter
• Test.Nunit: NUnit test project using Touchstone.NunitAdapter
• Test.Compatibility: Runs the Amazon S3 compatibility scenarios against S3Server or Amazon S3, or hosts the reference server for external clients

Run the test server (requires admin on Windows for wildcard listeners):

dotnet run --project src/Test.Server/Test.Server.csproj

Run the shared automated suite through each supported runner:

dotnet run --project src/Test.Automated/Test.Automated.csproj --framework net8.0
dotnet run --project src/Test.Automated/Test.Automated.csproj --framework net10.0
dotnet test src/Test.Xunit/Test.Xunit.csproj
dotnet test src/Test.Nunit/Test.Nunit.csproj

The xUnit and NUnit adapter projects execute these socket-bound integration descriptors serially to avoid local listener port races.

Amazon S3 Compatibility Tests

The Compatibility suite runs wire-level scenarios (ranges, HEAD ranges, parameter validation, listing shapes and pagination, encoding-type=url, conditional requests, response headers, CopyObject, multipart uploads including UploadPartCopy, DeleteObjects, ACLs, and error bodies). They are sent as raw SigV4-signed requests to S3Server running Test.Shared.Compatibility.ReferenceS3Backend, an in-memory backend, with signature validation enabled. Every expectation was recorded from Amazon S3, and Test.Compatibility can send the same scenarios to Amazon S3 to confirm they still hold:

# Against S3Server with the reference backend
dotnet run --project src/Test.Compatibility/Test.Compatibility.csproj -- --target local

# Against Amazon S3 (credentials are read from the environment, never from arguments)
export S3COMPAT_ACCESS_KEY=...
export S3COMPAT_SECRET_KEY=...
dotnet run --project src/Test.Compatibility/Test.Compatibility.csproj -- --target s3 --bucket my-bucket --region us-west-1

# Host the reference server for external clients (AWS CLI, boto3, MinIO client)
dotnet run --project src/Test.Compatibility/Test.Compatibility.csproj -- --serve 8000 --bucket compat-bucket

Against Amazon S3, the scenarios create objects only under a unique s3server-compat-* prefix and delete only that prefix afterward. They never change bucket settings or touch other objects.

Collect coverage for the library with the shared runsettings file:

dotnet test src/Test.Xunit/Test.Xunit.csproj --settings coverage.runsettings --collect:"XPlat Code Coverage"
dotnet test src/Test.Nunit/Test.Nunit.csproj --settings coverage.runsettings --collect:"XPlat Code Coverage"

Building from Source

# Build solution
dotnet build src/S3Server.sln

# Build specific configuration
dotnet build src/S3Server.sln -c Release

# Pack NuGet package
dotnet pack src/S3Server/S3Server.csproj -c Release

Dependencies

• Watson (7.1.0): HTTP server framework (supports HTTP/1.1, HTTP/2, and HTTP/3)
• AWSSignatureGenerator (1.1.0): AWS Signature V4 validation, streaming signature support, and legacy S3 Signature V2 helpers
• PrettyId (2.0.1): Request ID generation
• Touchstone (0.1.12): Shared test descriptors and console/xUnit/NUnit test runners

Resources

• Documentation: Amazon S3 REST API Reference
• Complete Example: Less3 - Production S3 Server
• NuGet Package: S3Server on NuGet

Feedback and Enhancements

Have a feature request or found an issue? Please file an issue on GitHub!

Version History

Refer to CHANGELOG.md for version history and release notes.

New in v8.0.1

• ListObjectVersions delete markers contain exactly Key, VersionId, IsLatest, LastModified, and Owner, with no xsi:nil ETag and no StorageClass
• DeleteObjects per-key errors are written as Key, VersionId, Code, Message, while standalone error bodies still start with Code
• No public API is removed or changed. See CHANGELOG.md for details

New in v8.0.0

This major release makes S3Server's responses match Amazon S3 in the details that 7.4.0 left out. Each behavior was checked against Amazon S3, and the new Compatibility suite enforces it. See CHANGELOG.md for breaking changes and migration notes.

• Querystring parameters are validated only by the operations that use them, with Amazon S3's exact errors (ArgumentName, ArgumentValue, and messages). partNumber must be 1 to 10000, and encoding-type must be url
• encoding-type=url listings are URL-encoded automatically, and ListObjects v1 and v2 responses take their exact Amazon S3 shapes
• HEAD honors Range, unsatisfiable ranges return 416 with RangeRequested and ActualObjectSize, and a suffix range on an empty object returns 200
• Error bodies carry Amazon S3's detail elements, and errors on HEAD have no body
• Timestamps are written with millisecond precision, as Amazon S3 does
• DeleteObjects honors Quiet, and malformed ACL bodies return MalformedACLError
• CORS and Accept-Charset headers are no longer sent by default (EmitCorsHeaders restores CORS for browser clients), and Connection: close follows the keep-alive setting
• New S3Request properties: KeyMarker, VersionIdMarker, UploadIdMarker, MaxUploads, EncodingType, and ValidationError
• New compatibility test tooling: the Compatibility suite and the Test.Compatibility runner

New in v7.4.0

This release fixes security, data integrity, and protocol accuracy problems found while building Less3's S3 compatibility suite. Some existing behavior changes; see CHANGELOG.md for details and opt-out settings.

• AuthenticatedRequestHandler runs after signature validation. ValidateSignaturesBeforePreRequestHandler moves validation ahead of PreRequestHandler, which by default sees unauthenticated input
• Canned ACL writes (x-amz-acl, x-amz-grant-*, empty body) reach WriteAcl with a null policy instead of failing
• Signature enforcement fails closed if Service.GetSecretKey is cleared after Start()
• Unparseable requests (for example max-keys=-1) return an S3 XML error instead of the webserver's HTML error page. Invalid numeric parameters return 400 InvalidArgument
• Malformed Range headers are ignored and the full object is served, as Amazon S3 does. Suffix ranges (bytes=-N) route to Object.ReadRange
• CopyObject and UploadPartCopy have their own request types and callbacks (Object.Copy, Object.UploadPartCopy) and are never delivered to Object.Write or Object.UploadPart as empty uploads
• Response bodies carry the S3 XML namespace, DeleteResult omits nil and false values, ListBucketResult adds NextMarker, StartAfter, and ContinuationToken, and ListVersionsResult.Entries interleaves versions and delete markers
• ErrorCode.NotModified sends a bodyless 304, and conditional request headers are parsed into typed properties
• Request-only headers (Host, Accept, Accept-Language, Cache-Control) are no longer echoed on every response

New in v7.3.2

• Upgrades to Watson 7.1.0 and refreshes the remaining dependencies to their latest stable versions
• Fixes S3 Select request parsing: invalid [XmlElement(IsNullable = true)] annotations on non-nullable value-type properties of the S3 Select models caused DeserializeXml<SelectObjectContentRequest> to throw for every SelectObjectContent request; the annotations were removed
• Fixes the S3Object.DataString setter, which truncated multibyte UTF-8 payloads by copying the character count instead of the byte count
• Expands automated test coverage with new positive/negative unit suites for the S3 data models and SerializationHelper (line coverage ~86% to ~94%, branch coverage ~63% to ~79%)
• No public API surface changes

New in v7.3.1

• Range (206 Partial Content) responses emit a real Content-Range total (bytes start-end/total) when the Object.ReadRange callback sets the new S3Object.TotalSize to the full object size
• Fixes ranged/multipart download clients such as the AWS CLI (aws s3 cp of large objects), which cannot parse the previous bytes start-end/* total
• Backward compatible: when TotalSize is not set, the Content-Range total remains * as before

New in v7.3.0

• Adds Service.IsAnonymousRequestAllowed for opt-in unsigned anonymous access when EnableSignatures is true
• Supports public-read/public-write-style compatibility while keeping unsigned requests rejected by default
• Keeps invalid signed requests fail-closed; requests with authorization or signed URL material do not fall back to anonymous access
• Adds signature validation coverage for allowed anonymous reads/writes, denied anonymous requests, invalid signed requests, and V4 presigned URL material

New in v7.2.0

• Adds opt-in legacy AWS Signature V2 validation behind S3ServerSettings.EnableSignatureV2
• Validates V2 Authorization: AWS ... headers and V2 signed URLs with AWSAccessKeyId, Expires, and Signature
• Keeps V2 disabled by default while preserving existing V4 validation behavior
• Adds canonical AWS Signature V2 fixture tests, V2 positive/negative request tests, and virtual-hosted-style request coverage
• Uses fixed-time comparison for V2 signature checks
• Serializes xUnit and NUnit adapter execution for socket-bound shared descriptors

New in v7.1.2

• Exposes each shared Touchstone scenario as a first-class descriptor across console, xUnit, and NUnit runners
• Adds parser/routing, protocol compatibility, adversarial, deterministic fuzz, lifecycle/concurrency, and deeper signature coverage
• Hardens S3 query parsing for common camel-case aliases used by V2 signed URLs and multipart requests
• Includes S3 request identifiers in XML error responses sent through S3Response.Send(Error)
• Adds coverage.runsettings for XPlat Code Coverage collection

New in v7.1.1

• Updated AWSSignatureGenerator to 1.1.0
• Migrated shared tests to Touchstone descriptors consumed by console, xUnit, and NUnit runners
• Added Test.Nunit
• Added stricter negative signature and restore-body coverage
• Added archive/V2_SIGNATURES.md with the end-to-end plan for V2 header and signed URL validation

New in v7.1.0

• Added Object.Restore callback support for POST ?restore
• Added typed restore request/result/status models
• S3Object and ObjectMetadata now emit x-amz-restore when RestoreStatus is supplied
• Added restore coverage in automated, compliance, xUnit, and signature validation tests

New in v7.0.5

• Watson 7.0.9 dependency update
• Fix UriFormatException when server is bound to wildcard hostname (*, +, 0.0.0.0)
• Signature validation fail-closed, range 206, unwired ops return 501
• Updated to Watson 7.0 (Watson.Lite removed; Watson now handles all transport modes natively)
• Target frameworks updated to .NET 8.0 and .NET 10.0 (dropped netstandard2.0, netstandard2.1, net6.0)
• Updated to AWSSignatureGenerator 1.0.12 with streaming signature validation (AWSSDK 4.x compatible)
• Updated to PrettyId 2.0.1
• AWS Signature V4 validation now supports streaming signatures (STREAMING-AWS4-HMAC-SHA256-PAYLOAD-TRAILER)
• MaxPutObjectSize check uses X-Amz-Decoded-Content-Length when aws-chunked encoding is in use
• Removed UseTcpServer setting (Watson 7.0 uses TCP natively)
• Added comprehensive test infrastructure (Test.Shared, Test.Xunit)
• Added signature validation test coverage using real AWSSDK 4.x client calls
• Added S3 compliance test suite

New in v6.0.x

• Breaking changes with dependency updates
• Moved usings inside namespaces to reduce collisions
• Moved from new byte[0] to Array.Empty<byte>()
• Size limits for ObjectWrite (e.g. PutObject), returns EntityTooLarge if exceeded
• Boolean for enabling or disabling signature validation
• Added multipart upload support (CreateMultipartUpload, UploadPart, CompleteMultipartUpload, AbortMultipartUpload, ReadParts)
• Added S3 Select API support (SelectContent)
• Added BucketReadMultipartUploads callback
• Added ObjectDeleteAcl callback
• Added UseTcpServer setting: when true, uses WatsonWebserver.Lite (TCP-based) instead of WatsonWebserver (http.sys-based)

License

MIT License - see LICENSE file for details
