OutWit.Database.Parser 1.0.0

OutWit.Database.Parser

WitSQL Parser - SQL parser for WitDatabase embedded database engine.

This library provides a complete SQL parser that converts WitSQL text into an Abstract Syntax Tree (AST) for execution by the database engine.

Overview

OutWit.Database.Parser is a high-performance SQL parser built on ANTLR4. It supports the full WitSQL dialect, which is designed to be compatible with SQLite while leveraging .NET's rich type system.

Key Features

• Complete SQL Support - DDL, DML, transactions, window functions, CTEs
• ANTLR4-based - Industry-standard parser generator
• Rich AST - Fully typed Abstract Syntax Tree
• Visitor Pattern - Easy AST traversal and transformation
• Expression Serializer - Convert AST back to SQL text
• Detailed Error Reporting - Line/column positions for syntax errors
• .NET 9/10 - Targets latest .NET versions

Installation

<PackageReference Include="OutWit.Database.Parser" Version="1.0.0" />

Quick Start

Parse SQL Statements

using OutWit.Database.Parser;

// Parse multiple statements
var statements = WitSql.Parse(@"
    CREATE TABLE Users (
        Id GUID PRIMARY KEY,
        Name VARCHAR(100) NOT NULL
    );

    INSERT INTO Users (Id, Name) VALUES (NEWGUID(), 'John');
");

foreach (var stmt in statements)
{
    Console.WriteLine(stmt.GetType().Name);
}
// Output:
// WitSqlStatementCreateTable
// WitSqlStatementInsert

Parse Single Statement

var stmt = WitSql.ParseStatement("SELECT * FROM Users WHERE Age > 18");

if (stmt is WitSqlStatementSelect select)
{
    Console.WriteLine($"From: {select.From[0].TableName}");
    // Output: From: Users
}

Parse Expression

var expr = WitSql.ParseExpression("Price * Quantity * (1 - Discount)");

if (expr is WitSqlExpressionBinary binary)
{
    Console.WriteLine($"Operator: {binary.Operator}");
}

Handle Parsing Errors

var result = WitSql.TryParse("SELECT * FORM Users"); // typo: FORM instead of FROM

if (!result.IsSuccess)
{
    foreach (var error in result.Errors)
    {
        Console.WriteLine($"Line {error.Line}, Column {error.Column}: {error.Message}");
    }
}

Architecture

Project Structure

OutWit.Database.Parser/
+-- Grammars/                    # ANTLR4 grammar files
|   +-- WitSqlLexer.g4          # Lexer rules (tokens)
|   +-- WitSqlParser.g4         # Parser rules (grammar)
+-- Expressions/                 # Expression AST nodes
|   +-- WitSqlExpression.cs     # Base class
|   +-- WitSqlExpressionBinary.cs
|   +-- WitSqlExpressionUnary.cs
|   +-- WitSqlExpressionLiteral.cs
|   +-- WitSqlExpressionColumnRef.cs
|   +-- WitSqlExpressionFunctionCall.cs
|   +-- WitSqlExpressionCase.cs
|   +-- WitSqlExpressionCast.cs
|   +-- WitSqlExpressionBetween.cs
|   +-- WitSqlExpressionIn.cs
|   +-- WitSqlExpressionLike.cs
|   +-- WitSqlExpressionGlob.cs
|   +-- WitSqlExpressionIsNull.cs
|   +-- WitSqlExpressionExists.cs
|   +-- WitSqlExpressionSubquery.cs
|   +-- WitSqlExpressionQuantified.cs
|   +-- WitSqlExpressionParameter.cs
|   +-- WitSqlExpressionIif.cs
|   +-- WitSqlExpressionCollate.cs
+-- Statements/                  # Statement AST nodes
|   +-- WitSqlStatement.cs      # Base class
|   +-- WitSqlStatementSelect.cs
|   +-- WitSqlStatementInsert.cs
|   +-- WitSqlStatementUpdate.cs
|   +-- WitSqlStatementDelete.cs
|   +-- WitSqlStatementMerge.cs
|   +-- WitSqlStatementCreateTable.cs
|   +-- WitSqlStatementDropTable.cs
|   +-- WitSqlStatementAlterTable.cs
|   +-- WitSqlStatementCreateIndex.cs
|   +-- WitSqlStatementDropIndex.cs
|   +-- WitSqlStatementCreateView.cs
|   +-- WitSqlStatementDropView.cs
|   +-- WitSqlStatementCreateTrigger.cs
|   +-- WitSqlStatementDropTrigger.cs
|   +-- WitSqlStatementCreateSequence.cs
|   +-- WitSqlStatementDropSequence.cs
|   +-- WitSqlStatementAlterSequence.cs
|   +-- WitSqlStatementTruncate.cs
|   +-- WitSqlStatementExplain.cs
|   +-- WitSqlStatementBeginTransaction.cs
|   +-- WitSqlStatementCommit.cs
|   +-- WitSqlStatementRollback.cs
|   +-- WitSqlStatementSavepoint.cs
|   +-- WitSqlStatementReleaseSavepoint.cs
|   +-- WitSqlStatementSetTransaction.cs
|   +-- WitSqlStatementSignal.cs
+-- Schema/                      # Supporting schema types
|   +-- WitSqlColumn.cs
|   +-- WitSqlDataType.cs
|   +-- Types/                   # Enums and type definitions
|   |   +-- BinaryOperator.cs
|   |   +-- UnaryOperatorType.cs
|   |   +-- LiteralType.cs
|   |   +-- JoinType.cs
|   |   +-- SetOperationType.cs
|   |   +-- IsolationLevelType.cs
|   |   +-- LockingType.cs
|   |   +-- ParameterType.cs
|   |   +-- QuantifierType.cs
|   |   +-- ...
|   +-- Clauses/                 # Clause definitions
|   |   +-- ClauseSelectItem.cs
|   |   +-- ClauseOrderByItem.cs
|   |   +-- ClauseCteDefinition.cs
|   |   +-- ClauseOnConflict.cs
|   |   +-- ...
|   +-- TableSources/            # FROM clause sources
|   |   +-- TableSource.cs
|   |   +-- TableSourceSimple.cs
|   |   +-- TableSourceJoin.cs
|   |   +-- TableSourceSubquery.cs
|   +-- ColumnConstraints/       # Column-level constraints
|   |   +-- ColumnConstraint.cs
|   |   +-- ColumnConstraintPrimaryKey.cs
|   |   +-- ColumnConstraintNotNull.cs
|   |   +-- ...
|   +-- TableConstraints/        # Table-level constraints
|   |   +-- TableConstraint.cs
|   |   +-- TableConstraintPrimaryKey.cs
|   |   +-- ...
|   +-- AlterActions/            # ALTER TABLE actions
|   |   +-- AlterAction.cs
|   |   +-- AlterActionAddColumn.cs
|   |   +-- ...
|   +-- MergeClauses/            # MERGE statement clauses
|       +-- ClauseMergeWhen.cs
+-- Visitor/                     # ANTLR visitor implementation
|   +-- WitSqlVisitor.cs         # Main visitor (partial)
|   +-- WitSqlVisitor.DDL.cs     # DDL statement handling
|   +-- WitSqlVisitor.DML.cs     # DML statement handling
|   +-- WitSqlVisitor.Expressions.cs
|   +-- WitSqlVisitor.Helpers.cs
+-- Serializers/                 # AST to SQL text
|   +-- WitSqlExpressionSerializer.cs
+-- Nodes/                       # Base AST node
|   +-- WitSqlNode.cs
+-- Interfaces/                  # Visitor interface
|   +-- IWitSqlVisitor.cs
+-- Exceptions/                  # Exception types
|   +-- WitSqlParsingException.cs
+-- WitSql.cs                    # Main entry point
+-- WitSqlParsingResult.cs       # Parsing result
+-- WitSqlParsingError.cs        # Error details
+-- WitSqlParsingErrorListener.cs

AST Class Hierarchy

WitSqlNode (abstract)
+-- WitSqlStatement (abstract)
|   +-- WitSqlStatementSelect
|   +-- WitSqlStatementInsert
|   +-- WitSqlStatementUpdate
|   +-- WitSqlStatementDelete
|   +-- WitSqlStatementMerge
|   +-- WitSqlStatementCreateTable
|   +-- WitSqlStatementDropTable
|   +-- WitSqlStatementAlterTable
|   +-- WitSqlStatementCreateIndex
|   +-- WitSqlStatementDropIndex
|   +-- WitSqlStatementCreateView
|   +-- WitSqlStatementDropView
|   +-- WitSqlStatementCreateTrigger
|   +-- WitSqlStatementDropTrigger
|   +-- WitSqlStatementCreateSequence
|   +-- WitSqlStatementDropSequence
|   +-- WitSqlStatementAlterSequence
|   +-- WitSqlStatementTruncate
|   +-- WitSqlStatementExplain
|   +-- WitSqlStatementBeginTransaction
|   +-- WitSqlStatementCommit
|   +-- WitSqlStatementRollback
|   +-- WitSqlStatementSavepoint
|   +-- WitSqlStatementReleaseSavepoint
|   +-- WitSqlStatementSetTransaction
|   +-- WitSqlStatementSignal
+-- WitSqlExpression (abstract)
    +-- WitSqlExpressionLiteral
    +-- WitSqlExpressionColumnRef
    +-- WitSqlExpressionBinary
    +-- WitSqlExpressionUnary
    +-- WitSqlExpressionFunctionCall
    +-- WitSqlExpressionCase
    +-- WitSqlExpressionCast
    +-- WitSqlExpressionBetween
    +-- WitSqlExpressionIn
    +-- WitSqlExpressionLike
    +-- WitSqlExpressionGlob
    +-- WitSqlExpressionIsNull
    +-- WitSqlExpressionExists
    +-- WitSqlExpressionSubquery
    +-- WitSqlExpressionQuantified
    +-- WitSqlExpressionParameter
    +-- WitSqlExpressionIif
    +-- WitSqlExpressionCollate

Supported SQL Features

Data Types

DDL Statements

• CREATE TABLE with all constraint types
• DROP TABLE
• ALTER TABLE (ADD/DROP COLUMN, RENAME, etc.)
• CREATE INDEX (unique, partial, expression, covering)
• DROP INDEX
• CREATE VIEW / DROP VIEW
• CREATE TRIGGER / DROP TRIGGER
• CREATE SEQUENCE / ALTER SEQUENCE / DROP SEQUENCE
• TRUNCATE TABLE

DML Statements

• SELECT with all clauses (WHERE, GROUP BY, HAVING, ORDER BY, LIMIT)
• INSERT with VALUES, SELECT, RETURNING
• UPDATE with FROM clause, RETURNING
• DELETE with USING clause, RETURNING
• MERGE (UPSERT)
• INSERT ... ON CONFLICT (UPSERT)

Joins and Set Operations

• INNER JOIN, LEFT JOIN, RIGHT JOIN, FULL JOIN, CROSS JOIN
• UNION, UNION ALL, INTERSECT, EXCEPT

Common Table Expressions (CTE)

• WITH ... AS
• WITH RECURSIVE ... AS
• Multiple CTEs

Subqueries

• Scalar subqueries
• Table subqueries (FROM clause)
• IN (subquery)
• EXISTS (subquery)
• ANY, SOME, ALL operators

Transactions

• BEGIN TRANSACTION
• COMMIT
• ROLLBACK
• SAVEPOINT / RELEASE SAVEPOINT
• SET TRANSACTION ISOLATION LEVEL
• Locking hints: FOR UPDATE, FOR SHARE, NOWAIT, SKIP LOCKED

Window Functions

• ROW_NUMBER(), RANK(), DENSE_RANK(), NTILE()
• LAG(), LEAD(), FIRST_VALUE(), LAST_VALUE(), NTH_VALUE()
• PERCENT_RANK(), CUME_DIST()
• OVER (PARTITION BY ... ORDER BY ... ROWS/RANGE ...)

Query Analysis

• EXPLAIN SELECT ...
• EXPLAIN QUERY PLAN SELECT ...

Built-in Functions

Parameters

-- Named parameters
SELECT * FROM Users WHERE Id = @UserId;
SELECT * FROM Users WHERE Name = :name;

-- Positional parameters
SELECT * FROM Users WHERE Id = ?;
SELECT * FROM Users WHERE Name = $1 AND Age = $2;

Collation

SELECT * FROM Users ORDER BY Name COLLATE NOCASE;

Visitor Pattern

The parser implements the visitor pattern for easy AST traversal:

public class MyVisitor : IWitSqlVisitor<string>
{
    public string VisitStatementSelect(WitSqlStatementSelect node)
    {
        return $"SELECT from {node.From.Count} tables";
    }

    public string VisitExpressionBinary(WitSqlExpressionBinary node)
    {
        var left = node.Left.Accept(this);
        var right = node.Right.Accept(this);
        return $"({left} {node.Operator} {right})";
    }

    // ... implement other Visit methods
}

Expression Serialization

Convert AST back to SQL text:

using OutWit.Database.Parser.Serializers;

var expr = WitSql.ParseExpression("a + b * c");
var sql = WitSqlExpressionSerializer.Serialize(expr);
// Output: "(a + (b * c))"

Dependencies

Related Projects

License

Licensed under the Apache License, Version 2.0. See LICENSE.

Attribution (optional)

If you use OutWit.Database.Parser in a product, a mention is appreciated (but not required), for example: "Powered by WitDatabase https://witdatabase.io/".

Trademark / Project name

"WitDatabase" and the WitDatabase logo are used to identify the official project by Dmitry Ratner.

You may:

• refer to the project name in a factual way (e.g., "built with WitDatabase");
• use the name to indicate compatibility (e.g., "WitDatabase-compatible").

You may not:

• use "WitDatabase" as the name of a fork or a derived product in a way that implies it is the official project;
• use the WitDatabase logo to promote forks or derived products without permission.

See Also

• WitSql.md - Full WitSQL language specification
• ROADMAP.md - Version 2.0 planned features
• ROADMAP.md - Main project roadmap
