OutWit.Database 1.0.0

OutWit.Database

WitSQL Engine - SQL execution engine for WitDatabase embedded database.

This library provides the complete SQL execution layer that transforms parsed SQL statements into query results using the underlying storage engine.

Overview

OutWit.Database is the SQL execution engine built on top of OutWit.Database.Core (storage layer) and OutWit.Database.Parser (SQL parser). It implements the Volcano/Iterator model for query execution and supports a comprehensive set of SQL features.

Key Features

• Complete SQL Execution - DDL, DML, transactions, window functions, CTEs
• Iterator-Based Query Engine - Volcano model for efficient query execution
• Expression Evaluation - 60+ built-in functions
• Transaction Support - Full ACID with savepoints and isolation levels
• Index Support - Seek, range scan, partial, expression, and covering indexes
• Query Optimization - Cost-based index selection, join ordering, plan caching
• Window Functions - ROW_NUMBER, RANK, LAG, LEAD, aggregates OVER
• JSON Support - Full JSON manipulation functions
• .NET 9/10 - Targets latest .NET versions

Installation

<PackageReference Include="OutWit.Database" Version="1.0.0" />

Quick Start

Create Engine Instance

using OutWit.Database.Core.Builder;
using OutWit.Database.Engine;

// Create in-memory database
var database = new WitDatabaseBuilder()
    .WithMemoryStorage()
    .Build();

using var engine = new WitSqlEngine(database, ownsStore: true);

Execute SQL Queries

// Create table
engine.Execute(@"
    CREATE TABLE Users (
        Id GUID PRIMARY KEY,
        Name VARCHAR(100) NOT NULL,
        Email VARCHAR(255) UNIQUE,
        Age INT CHECK (Age >= 0),
        CreatedAt DATETIME DEFAULT NOW()
    )
");

// Insert data
engine.Execute(@"
    INSERT INTO Users (Id, Name, Email, Age)
    VALUES (NEWGUID(), 'John Doe', 'john@example.com', 30)
");

// Query with parameters
var result = engine.Execute(
    "SELECT * FROM Users WHERE Age > @minAge",
    new Dictionary<string, object?> { ["minAge"] = 25 }
);

foreach (var row in result)
{
    Console.WriteLine($"{row["Name"]} - {row["Email"]}");
}

Transactions

engine.Execute("BEGIN TRANSACTION");

try
{
    engine.Execute("INSERT INTO Users (Id, Name) VALUES (NEWGUID(), 'Alice')");
    engine.Execute("INSERT INTO Users (Id, Name) VALUES (NEWGUID(), 'Bob')");
    engine.Execute("COMMIT");
}
catch
{
    engine.Execute("ROLLBACK");
    throw;
}

Savepoints

engine.Execute("BEGIN TRANSACTION");
engine.Execute("INSERT INTO Users (Id, Name) VALUES (NEWGUID(), 'Alice')");

engine.Execute("SAVEPOINT sp1");
engine.Execute("INSERT INTO Users (Id, Name) VALUES (NEWGUID(), 'Bob')");

// Rollback to savepoint (keeps Alice, removes Bob)
engine.Execute("ROLLBACK TO SAVEPOINT sp1");

engine.Execute("COMMIT");

Query Timeout

// Set default timeout
engine.DefaultQueryTimeout = TimeSpan.FromSeconds(30);

// Or per-query timeout
var result = engine.Execute(
    "SELECT * FROM LargeTable",
    parameters: null,
    timeout: TimeSpan.FromSeconds(5)
);

Architecture

Project Structure

OutWit.Database/
+-- Engine/                      # Main engine entry point
|   +-- WitSqlEngine.cs          # SQL engine facade
|   +-- WitSqlEngine.Query.cs
|   +-- WitSqlEngine.Ddl.*.cs    # DDL operations
|   +-- WitSqlEngine.Dml.*.cs    # DML operations
|   +-- WitSqlEngine.Transactions.cs
+-- Statements/                  # Statement execution
|   +-- StatementExecutor.cs     # Main executor
|   +-- StatementExecutor.Select.cs
|   +-- StatementExecutor.Insert.cs
|   +-- StatementExecutor.Update.cs
|   +-- StatementExecutor.Delete.cs
|   +-- StatementExecutor.Merge.cs
|   +-- StatementExecutor.Ddl.*.cs
|   +-- StatementExecutor.Transactions.cs
|   +-- StatementExecutor.Explain.cs
+-- Query/                       # Query planning
|   +-- QueryPlanner.cs          # Iterator tree builder
|   +-- QueryPlanner.Sources.cs  # FROM clause handling
|   +-- QueryPlanner.Clauses.cs  # WHERE, ORDER BY, etc.
|   +-- QueryPlanner.Cte.cs      # CTE handling
|   +-- QueryPlanCache.cs        # Query plan caching
+-- Optimizers/                  # Query optimization
|   +-- OptimizerQuery.cs        # Index selection
|   +-- OptimizerJoinOrder.cs    # Join ordering
+-- Expressions/                 # Expression evaluation
|   +-- ExpressionEvaluator.cs   # Main evaluator
|   +-- ExpressionEvaluator.Functions.cs
|   +-- ExpressionEvaluator.Aggregate.cs
|   +-- ExpressionEvaluator.Subquery.cs
|   +-- ExpressionEvaluator.Json.cs
+-- Iterators/                   # Query execution operators
|   +-- IteratorBase.cs
|   +-- IteratorTableScan.cs
|   +-- IteratorIndexSeek.cs
|   +-- IteratorIndexRangeScan.cs
|   +-- IteratorFilter.cs
|   +-- IteratorProject.cs
|   +-- IteratorSort.cs
|   +-- IteratorGroupBy.cs
|   +-- IteratorJoin.cs
|   +-- IteratorWindow.cs
|   +-- IteratorUnion.cs
|   +-- IteratorIntersect.cs
|   +-- IteratorExcept.cs
|   +-- IteratorLimit.cs
|   +-- IteratorDistinct.cs
|   +-- IteratorLocking.cs
+-- Schema/                      # Database schema management
|   +-- SchemaCatalog.cs
|   +-- SchemaCatalog.Tables.cs
|   +-- SchemaCatalog.Indexes.cs
|   +-- SchemaCatalog.Views.cs
|   +-- SchemaCatalog.Triggers.cs
|   +-- SchemaCatalog.Information.*.cs
+-- Definitions/                 # Schema definitions
|   +-- DefinitionTable.cs
|   +-- DefinitionColumn.cs
|   +-- DefinitionIndex.cs
|   +-- DefinitionView.cs
|   +-- DefinitionTrigger.cs
|   +-- DefinitionSequence.cs
+-- Values/                      # SQL value types
|   +-- WitSqlValue.cs           # Variant type
|   +-- WitSqlValue.Operations.cs
|   +-- WitSqlValue.Comparison.cs
|   +-- WitSqlValue.Json.cs
+-- Types/                       # Type system
|   +-- WitSqlType.cs
|   +-- WitDataType.cs
|   +-- WitTypeConverter.cs
+-- Sql/                         # Result types
|   +-- WitSqlResult.cs
|   +-- WitSqlRow.cs
|   +-- WitSqlColumnInfo.cs
+-- Context/                     # Execution context
|   +-- ContextExecution.cs
|   +-- ContextTrigger.cs
+-- Transactions/                # Transaction handling
    +-- TransactionHandle.cs

Iterator Model

The engine uses the Volcano/Iterator model where each query operation is represented as an iterator:

IteratorProject (SELECT columns)
    |
IteratorSort (ORDER BY)
    |
IteratorFilter (WHERE)
    |
IteratorJoin (JOIN)
   / \
IteratorTableScan  IteratorIndexSeek

Each iterator implements IResultIterator:

• Open() - Initialize the iterator
• MoveNext() - Advance to next row
• Current - Get current row
• Schema - Get column schema
• Dispose() - Clean up resources

Supported SQL Features

Data Types

DDL Statements

• CREATE TABLE with all constraint types (PK, FK, UNIQUE, CHECK, DEFAULT)
• DROP TABLE [IF EXISTS]
• ALTER TABLE (ADD/DROP COLUMN, ADD/DROP CONSTRAINT, RENAME)
• CREATE INDEX (unique, partial, expression, covering)
• DROP INDEX
• CREATE VIEW / DROP VIEW
• CREATE TRIGGER / DROP TRIGGER (BEFORE/AFTER/INSTEAD OF)
• CREATE SEQUENCE / ALTER SEQUENCE / DROP SEQUENCE
• TRUNCATE TABLE

DML Statements

• SELECT with all clauses (WHERE, GROUP BY, HAVING, ORDER BY, LIMIT)
• INSERT with VALUES, SELECT, RETURNING, ON CONFLICT
• UPDATE with FROM clause, RETURNING
• DELETE with USING clause, RETURNING
• MERGE (UPSERT with WHEN MATCHED/NOT MATCHED)

Joins and Set Operations

• INNER JOIN, LEFT JOIN, RIGHT JOIN, FULL JOIN, CROSS JOIN
• UNION, UNION ALL, INTERSECT, EXCEPT

Subqueries

• Scalar subqueries
• Table subqueries (FROM clause)
• IN (subquery), NOT IN (subquery)
• EXISTS, NOT EXISTS
• ANY, SOME, ALL
• Correlated subqueries

Common Table Expressions (CTE)

WITH ActiveUsers AS (
    SELECT * FROM Users WHERE IsActive = TRUE
)
SELECT * FROM ActiveUsers WHERE Age > 18;

-- Recursive CTE
WITH RECURSIVE Numbers(n) AS (
    SELECT 1
    UNION ALL
    SELECT n + 1 FROM Numbers WHERE n < 10
)
SELECT * FROM Numbers;

Window Functions

SELECT
    Name,
    Department,
    Salary,
    ROW_NUMBER() OVER (PARTITION BY Department ORDER BY Salary DESC) AS Rank,
    SUM(Salary) OVER (PARTITION BY Department) AS DeptTotal,
    LAG(Salary) OVER (ORDER BY Salary) AS PrevSalary
FROM Employees;

Supported functions:

• Ranking: ROW_NUMBER, RANK, DENSE_RANK, NTILE, PERCENT_RANK, CUME_DIST
• Value: LAG, LEAD, FIRST_VALUE, LAST_VALUE, NTH_VALUE
• Aggregate: SUM, AVG, COUNT, MIN, MAX with OVER clause
• Frame: ROWS/RANGE BETWEEN ... AND ...

Transactions

BEGIN TRANSACTION;
SET TRANSACTION ISOLATION LEVEL SERIALIZABLE;

-- Statements with row-level locking
SELECT * FROM Orders WHERE Status = 'pending' FOR UPDATE NOWAIT;

SAVEPOINT sp1;
-- More operations
ROLLBACK TO SAVEPOINT sp1;

COMMIT;

Supported isolation levels:

• READ UNCOMMITTED
• READ COMMITTED
• REPEATABLE READ
• SERIALIZABLE
• SNAPSHOT

Built-in Functions

JSON Functions

-- Extract values
SELECT JSON_VALUE(data, '$.name') FROM Documents;
SELECT JSON_QUERY(data, '$.items') FROM Documents;

-- Modify JSON
UPDATE Documents SET data = JSON_SET(data, '$.status', 'active');
UPDATE Documents SET data = JSON_REMOVE(data, '$.temp');

-- Construct JSON
SELECT JSON_OBJECT('id', Id, 'name', Name) FROM Users;
SELECT JSON_ARRAY(1, 2, 3);

INFORMATION_SCHEMA

SELECT * FROM INFORMATION_SCHEMA.TABLES;
SELECT * FROM INFORMATION_SCHEMA.COLUMNS WHERE TABLE_NAME = 'Users';
SELECT * FROM INFORMATION_SCHEMA.INDEXES;
SELECT * FROM INFORMATION_SCHEMA.KEY_COLUMN_USAGE;
SELECT * FROM INFORMATION_SCHEMA.TABLE_CONSTRAINTS;
SELECT * FROM INFORMATION_SCHEMA.REFERENTIAL_CONSTRAINTS;
SELECT * FROM INFORMATION_SCHEMA.VIEWS;

EXPLAIN

-- Show query plan
EXPLAIN SELECT * FROM Users WHERE Age > 18;

-- Show detailed query plan
EXPLAIN QUERY PLAN SELECT * FROM Orders o JOIN Users u ON o.UserId = u.Id;

Query Optimization

Index Selection

The optimizer automatically selects appropriate indexes based on:

• WHERE clause predicates
• Join conditions
• Cost estimation (row count, index selectivity)

-- Creates index
CREATE INDEX IX_Users_Age ON Users (Age);

-- Optimizer will use index for this query
SELECT * FROM Users WHERE Age > 18;

Query Plan Caching

Parsed statements and query plans are cached for repeated queries:

// First execution: parse + plan + execute
engine.Execute("SELECT * FROM Users WHERE Id = @id", new { id = 1 });

// Second execution: use cached plan
engine.Execute("SELECT * FROM Users WHERE Id = @id", new { id = 2 });

// Access cache statistics
Console.WriteLine($"Cache hits: {engine.PlanCache.Hits}");
Console.WriteLine($"Cache misses: {engine.PlanCache.Misses}");

Join Order Optimization

For multi-table queries, the optimizer reorders joins to minimize intermediate result sizes:

-- Optimizer may reorder joins based on table statistics
SELECT * FROM Orders o
JOIN Users u ON o.UserId = u.Id
JOIN Products p ON o.ProductId = p.Id
WHERE u.Country = 'USA';

Computed Columns

STORED Computed Columns

CREATE TABLE Orders (
    Quantity INT NOT NULL,
    UnitPrice DECIMAL(10,2) NOT NULL,
    TotalPrice AS (Quantity * UnitPrice) STORED
);

-- TotalPrice is automatically calculated on INSERT/UPDATE
INSERT INTO Orders (Quantity, UnitPrice) VALUES (5, 10.00);
-- TotalPrice = 50.00

VIRTUAL Computed Columns

CREATE TABLE Products (
    Price DECIMAL(10,2) NOT NULL,
    TaxRate DECIMAL(4,2) NOT NULL,
    PriceWithTax AS (Price * (1 + TaxRate)) -- VIRTUAL by default
);

-- PriceWithTax is calculated on-the-fly during SELECT
SELECT Name, PriceWithTax FROM Products;

Triggers

-- Audit trigger
CREATE TRIGGER AuditUserChanges
AFTER UPDATE ON Users
FOR EACH ROW
BEGIN
    INSERT INTO AuditLog (TableName, OldValue, NewValue, ChangedAt)
    VALUES ('Users', OLD.Name, NEW.Name, NOW());
END;

-- Validation trigger
CREATE TRIGGER ValidateOrderAmount
BEFORE INSERT ON Orders
FOR EACH ROW
WHEN (NEW.Amount < 0)
BEGIN
    SIGNAL SQLSTATE '45000' SET MESSAGE_TEXT = 'Amount cannot be negative';
END;

Dependencies

Related Projects

Test Coverage

License

Licensed under the Apache License, Version 2.0. See LICENSE.

Attribution (optional)

If you use OutWit.Database in a product, a mention is appreciated (but not required), for example: "Powered by WitDatabase https://witdatabase.io/".

Trademark / Project name

"WitDatabase" and the WitDatabase logo are used to identify the official project by Dmitry Ratner.

You may:

• refer to the project name in a factual way (e.g., "built with WitDatabase");
• use the name to indicate compatibility (e.g., "WitDatabase-compatible").

You may not:

• use "WitDatabase" as the name of a fork or a derived product in a way that implies it is the official project;
• use the WitDatabase logo to promote forks or derived products without permission.

Performance Considerations

INSERT Performance with PRIMARY KEY

WitDatabase does not automatically create indexes on PRIMARY KEY columns. This is by design to give you full control over your database schema.

AUTOINCREMENT Primary Keys (Fast ?)

When using AUTOINCREMENT, uniqueness is guaranteed by the internal sequence generator, so no validation scan is needed:

CREATE TABLE Users (
    Id BIGINT PRIMARY KEY AUTOINCREMENT,
    Name VARCHAR(100)
);

-- Fast: ~0.02ms per insert (no uniqueness check needed)
INSERT INTO Users (Name) VALUES ('Alice');

Explicit Primary Keys (Slow Without Index ??)

When you explicitly provide PK values, the engine must validate uniqueness. Without an index, this requires a full table scan per insert (O(n) per insert = O(n�) total for batch inserts):

CREATE TABLE Items (
    Id INT PRIMARY KEY,  -- NOT AUTOINCREMENT
    Name VARCHAR(100)
);

-- Slow: ~0.35ms per insert with full table scan
INSERT INTO Items (Id, Name) VALUES (1, 'Item1');

Solution: Create Explicit Index (Fast ?)

For explicit PK values, create a UNIQUE index to enable O(log n) validation:

CREATE TABLE Items (
    Id INT PRIMARY KEY,
    Name VARCHAR(100)
);

-- Add explicit unique index for fast uniqueness checks
CREATE UNIQUE INDEX IX_Items_Id ON Items(Id);

-- Now fast: ~0.07ms per insert (uses index seek)
INSERT INTO Items (Id, Name) VALUES (1, 'Item1');

Performance Summary

Recommendation

For best INSERT performance:

1. Prefer AUTOINCREMENT - Let the database generate unique IDs
2. Create explicit indexes - If you must use explicit PKs, add a UNIQUE index
3. Use prepared statements - Reuse parsed statements via engine.Prepare()
4. Batch in transactions - Wrap multiple INSERTs in a transaction

// Best practice for explicit PK scenario
engine.Execute(@"
    CREATE TABLE Products (
        SKU VARCHAR(50) PRIMARY KEY,
        Name VARCHAR(200),
        Price DECIMAL(10,2)
    )
");

// Create index for fast uniqueness validation
engine.Execute("CREATE UNIQUE INDEX IX_Products_SKU ON Products(SKU)");

See Also

• WitSql.md - Full WitSQL language specification
• ROADMAP.md - Version 2.0 planned features
• ROADMAP.md - Main project roadmap
