Forge.Next.Security
A small, focused .NET library for X.509 certificate management and AES encryption — with first-class support for self-signed certificates (local development, internal services, TLS endpoints) and password-based symmetric encryption.
Every public method returns an ErrorOr<T> result instead of throwing, so failures are values you handle explicitly rather than exceptions you have to catch.
It is part of the Forge Patterns and Practices family.
Table of contents
- Features
- Requirements
- Installation
- Working with
ErrorOrresults - API reference
- How Subject Alternative Names are built
- End-to-end example
- Notes, gotchas & platform behaviour
- Security notes
- Testing
- License
Features
- 🔐 Self-signed certificate generation with sensible, secure defaults (RSA 2048, SHA-256, TLS Server Authentication EKU) and a configurable key size.
- 🌐 Automatic Subject Alternative Names (SAN) — loopback, "any",
localhostand the machine name are always included, plus any custom DNS names / IP addresses you supply. - 💾 Export & import to/from PFX (PKCS#12) raw bytes or files, and export the public certificate as a
.cer(DER) file. - 🗄️ Certificate store management — add, find (by thumbprint or by DNS name), enumerate and remove certificates from the Windows/OS certificate store.
- 🧂 AES encryption — PBKDF2 key derivation plus authenticated AES-256-GCM encryption; the legacy AES-CBC
iv:ciphertextpayload stays readable. - ✅ Exception-free API — every method returns
ErrorOr<T>; nothing throws for expected failures.
All types live in the Forge.Next.Security namespace.
Requirements
| Target frameworks | net8.0, net9.0, net10.0, net11.0 |
| Language | C# 12 |
| Dependencies | Forge.Next.Shared (brings in ErrorOr) |
| Platforms | Cross-platform. Certificate-store and friendly-name features are richest on Windows (see platform notes). |
Installation
dotnet add package Forge.Next.Security
or via the Package Manager Console:
Install-Package Forge.Next.Security
Then import the namespaces:
using Forge.Next.Security; // CertificateFactory, CertificateAccess, AesCryptography
using ErrorOr; // ErrorOr<T>, Error, ErrorType
using System.Security.Cryptography.X509Certificates; // X509Certificate2, StoreName, StoreLocation
Working with ErrorOr results
Because every method returns ErrorOr<T>, you never wrap calls in try/catch for expected failures. Inspect the result instead:
ErrorOr<X509Certificate2> result = CertificateFactory.GetForLocalhost("CN=localhost", "Dev HTTPS");
if (result.IsError)
{
// result.FirstError.Type is an ErrorType (Validation, NotFound, Unexpected, …)
Console.WriteLine($"Failed: {result.FirstError.Type} - {result.FirstError.Description}");
}
else
{
X509Certificate2 certificate = result.Value; // safe to read once IsError is false
Console.WriteLine(certificate.Thumbprint);
}
Or use the functional helpers shipped with ErrorOr:
// Match: project both branches into a single value.
string message = result.Match(
cert => $"Created {cert.Thumbprint}",
errors => $"Failed: {errors[0].Description}");
// Then / ThenDo: chain further work that only runs on success.
ErrorOr<byte[]> pfx = CertificateFactory
.GetForLocalhost("CN=localhost", "Dev HTTPS")
.Then(cert => CertificateFactory.ExportToPfxRawData(cert, "p@ss"));
The error kinds this library produces are:
ErrorType |
When |
|---|---|
Validation |
A required argument was null (e.g. a null password/salt). The Description names the offending parameter. |
NotFound |
CertificateAccess.FindByThumbprint found no matching certificate. |
Unexpected |
An underlying operation threw (wrong PFX password, missing file, …); the exception is caught and converted into this error. |
In the examples below, code that is not specifically demonstrating error handling reads
.Valuedirectly for brevity. In production, guard withIsError(orMatch) first.
API reference
| Class | Responsibility |
|---|---|
CertificateFactory |
Create, export and import self-signed certificates. |
CertificateAccess |
Read from and write to the OS certificate store; inspect SAN entries. |
AesCryptography |
Derive AES keys (PBKDF2) and encrypt/decrypt strings (authenticated AES-GCM; the legacy AES-CBC format stays readable). |
CertificateFactory
public static class CertificateFactory
Creates and manages self-signed certificates. Generated certificates use an RSA key (2048-bit by default, configurable), a SHA-256/PKCS#1 signature, the TLS Server Authentication enhanced key usage (1.3.6.1.5.5.7.3.1), the DigitalSignature | KeyEncipherment | DataEncipherment key usages, and are flagged as non-CA (end-entity) certificates.
| Member | Returns | Summary |
|---|---|---|
Localhost |
const string |
The constant "localhost". |
CreateSelfSigned(string, string, IEnumerable<string>, DateTime, DateTime, int) |
ErrorOr<X509Certificate2> |
Create an in-memory self-signed certificate. |
CreateSelfSigned(string, string, IEnumerable<string>, DateTime, DateTime, string, int, X509KeyStorageFlags) |
ErrorOr<X509Certificate2> |
Create a certificate and round-trip it through a password-protected PFX (machine key set). |
ExportToPfxRawData(X509Certificate2, string) |
ErrorOr<byte[]> |
Export the certificate and private key as PFX bytes. |
ExportToCerFile(X509Certificate2) |
ErrorOr<byte[]> |
Export the public certificate as DER (.cer) bytes. |
GetForLocalhost(string, string, int) |
ErrorOr<X509Certificate2> |
Create a long-lived certificate for localhost. |
GetFromRawData(byte[], string, X509KeyStorageFlags) |
ErrorOr<X509Certificate2> |
Load a certificate from PFX bytes. |
GetFromFile(string, string?, X509KeyStorageFlags) |
ErrorOr<X509Certificate2> |
Load a certificate from a PFX file. |
Localhost (constant)
public const string Localhost = "localhost";
The lower-case DNS label "localhost". Useful when you want to reference the same value the factory uses internally.
string name = CertificateFactory.Localhost; // "localhost"
CreateSelfSigned (without password)
public static ErrorOr<X509Certificate2> CreateSelfSigned(
string x500,
string friendlyName,
IEnumerable<string> dnsNames,
DateTime startTime,
DateTime endTime,
int keySize = 2048)
Creates a brand-new, in-memory (ephemeral) self-signed certificate that owns its freshly generated private key. Nothing is written to disk or to a certificate store.
Parameters
| Name | Type | Description |
|---|---|---|
x500 |
string |
The X.500 subject distinguished name (e.g. "CN=My Company"). null is treated as an empty subject. |
friendlyName |
string |
The Windows friendly name. Applied only on Windows; ignored on other platforms. |
dnsNames |
IEnumerable<string> |
Additional DNS names and/or IP addresses to add to the SAN. See how SANs are built. |
startTime |
DateTime |
Validity start (NotBefore). A DateTime whose Kind is not Utc is local time. |
endTime |
DateTime |
Validity end (NotAfter), the same way. A local time whose UTC equivalent falls outside DateTime's range (DateTime.MaxValue west of UTC, DateTime.MinValue east of it) is clamped to the range instead of failing. |
keySize |
int |
RSA key size in bits. Defaults to 2048. |
Example
ErrorOr<X509Certificate2> result = CertificateFactory.CreateSelfSigned(
x500: "CN=My Company, O=My Company Ltd, C=US",
friendlyName: "My Internal Service",
dnsNames: new[] { "myapp.local", "api.myapp.local", "192.168.1.50" },
startTime: DateTime.UtcNow.AddDays(-1),
endTime: DateTime.UtcNow.AddYears(5),
keySize: 4096);
if (!result.IsError)
{
X509Certificate2 certificate = result.Value;
Console.WriteLine(certificate.Subject); // CN=My Company, O=My Company Ltd, C=US
Console.WriteLine(certificate.HasPrivateKey); // True
}
💡 Use
DateTime.UtcNowfor the validity boundaries so the encoded values are unambiguous across time zones.
CreateSelfSigned (with password)
public static ErrorOr<X509Certificate2> CreateSelfSigned(
string x500,
string friendlyName,
IEnumerable<string> dnsNames,
DateTime startTime,
DateTime endTime,
string password,
int keySize = 2048,
X509KeyStorageFlags keyStorageFlags =
X509KeyStorageFlags.Exportable | X509KeyStorageFlags.PersistKeySet | X509KeyStorageFlags.MachineKeySet)
Same as the overload above, but after creation the certificate is exported to a password-protected PFX and re-imported, by default with X509KeyStorageFlags.Exportable | PersistKeySet | MachineKeySet. Use this overload when you need the private key persisted in the machine key store (for example, a Windows service that must access the key across processes/sessions, or a TLS server on Windows: SChannel fails the handshake with an ephemeral key). The key stays there after the certificate is disposed: every call adds one, and nothing in this package removes it (see Notes for removing one).
Parameters — identical to the overload above, plus a password (the password protecting the intermediate PFX round-trip), with keySize after it, and keyStorageFlags last: the flags of the re-import (see GetFromRawData). Pass X509KeyStorageFlags.EphemeralKeySet to keep the key in memory only; macOS has no ephemeral key sets.
Example
ErrorOr<X509Certificate2> result = CertificateFactory.CreateSelfSigned(
x500: "CN=My Windows Service",
friendlyName: "My Service Certificate",
dnsNames: new[] { "service.internal" },
startTime: DateTime.UtcNow.AddDays(-1),
endTime: DateTime.UtcNow.AddYears(2),
password: "S3cr3t!Passw0rd");
Console.WriteLine(result.IsError ? result.FirstError.Description : result.Value.HasPrivateKey);
⚠️ Permissions:
MachineKeySetwrites to the machine-wide key container. On Windows this typically requires the process to run elevated (as Administrator). If you only need an in-memory key, prefer the password-less overload.
ExportToPfxRawData
public static ErrorOr<byte[]> ExportToPfxRawData(X509Certificate2 certificate, string password)
Exports the certificate including its private key as PFX/PKCS#12 raw bytes, protected by password. The result can later be re-imported with GetFromRawData or GetFromFile.
The protection depends on the target framework:
| Target | Key and certificate | MAC | Iterations |
|---|---|---|---|
net10.0, net11.0 |
PBES2: PBKDF2 with HMAC-SHA-256, AES-256-CBC (ExportPkcs12 with Pkcs12ExportPbeParameters.Pbes2Aes256Sha256) |
SHA-256 | 2,000 |
net8.0, net9.0 |
Legacy pbeWithSHAAnd3-KeyTripleDES-CBC (these frameworks have no ExportPkcs12) |
SHA-1 | 2,000 |
(OpenSSL pkcs12 -info on exports made on Windows.) Current Windows, .NET and OpenSSL read both forms; an old importer that reads only the TripleDES form cannot read an export made on net10.0 or later.
Example
X509Certificate2 certificate = CertificateFactory.GetForLocalhost("CN=localhost", "Dev").Value;
ErrorOr<byte[]> pfx = CertificateFactory.ExportToPfxRawData(certificate, "S3cr3t!Passw0rd");
if (!pfx.IsError)
File.WriteAllBytes("mycert.pfx", pfx.Value);
ExportToCerFile
public static ErrorOr<byte[]> ExportToCerFile(X509Certificate2 certificate)
Exports the public certificate only (no private key) as DER-encoded .cer bytes. This is the file you distribute to clients that need to trust your certificate.
Example
ErrorOr<byte[]> cer = CertificateFactory.ExportToCerFile(certificate);
if (!cer.IsError)
{
File.WriteAllBytes("mycert.cer", cer.Value);
// Re-loading the .cer yields a certificate WITHOUT a private key
// (net9.0 and later; on net8.0 use new X509Certificate2(cer.Value)):
var publicOnly = X509CertificateLoader.LoadCertificate(cer.Value);
Console.WriteLine(publicOnly.HasPrivateKey); // False
}
GetForLocalhost
public static ErrorOr<X509Certificate2> GetForLocalhost(string subject, string friendlyName, int keySize = 2048)
Convenience method that creates a self-signed certificate already valid (NotBefore = yesterday) and effectively non-expiring (NotAfter = 9999-12-31 23:59:59 UTC, in every time zone), with the default localhost / loopback SAN entries. Ideal for local HTTPS during development.
Reading
NotAftereast of UTC:X509Certificate2.NotAfteris local time, and 9999-12-31 23:59:59 UTC is beyond the last local time aDateTimecan hold east of UTC, so there the property returnsDateTime.MaxValue(and.ToUniversalTime()of it is earlier by the offset). The time in the certificate itself is 23:59:59 UTC.
Parameters
| Name | Type | Description |
|---|---|---|
subject |
string |
The subject name (e.g. "CN=localhost"). |
friendlyName |
string |
The Windows friendly name. |
keySize |
int |
RSA key size in bits. Defaults to 2048. |
Example
ErrorOr<X509Certificate2> result = CertificateFactory.GetForLocalhost(
subject: "CN=localhost",
friendlyName: "Local Dev HTTPS");
Console.WriteLine(result.Value.NotAfter.Year); // 9999
GetFromRawData
public static ErrorOr<X509Certificate2> GetFromRawData(
byte[] certificateData,
string password,
X509KeyStorageFlags keyStorageFlags =
X509KeyStorageFlags.Exportable | X509KeyStorageFlags.PersistKeySet | X509KeyStorageFlags.MachineKeySet)
Loads a certificate (with private key) from PFX/PKCS#12 raw bytes, by default with
Exportable | PersistKeySet | MachineKeySet, so the private key stays in the machine key store (see Notes). The inverse of ExportToPfxRawData.
Parameters
| Name | Type | Description |
|---|---|---|
certificateData |
byte[] |
The PFX/PKCS#12 bytes. |
password |
string |
The PFX password. |
keyStorageFlags |
X509KeyStorageFlags |
The storage flags of the load. The default persists the private key in the machine key store, as a Windows TLS server (SChannel) and a key shared across processes need. X509KeyStorageFlags.EphemeralKeySet keeps it in memory only and writes nothing to disk (not on macOS). A combination the platform rejects (for example EphemeralKeySet with PersistKeySet) is returned as an ErrorType.Unexpected error. |
Example
byte[] pfxBytes = File.ReadAllBytes("mycert.pfx");
ErrorOr<X509Certificate2> result = CertificateFactory.GetFromRawData(pfxBytes, "S3cr3t!Passw0rd");
// A wrong password does not throw — it returns an ErrorType.Unexpected error:
if (result.IsError)
Console.WriteLine(result.FirstError.Type); // Unexpected
else
Console.WriteLine(result.Value.HasPrivateKey); // True
GetFromFile
public static ErrorOr<X509Certificate2> GetFromFile(
string certificateFile,
string? password,
X509KeyStorageFlags keyStorageFlags =
X509KeyStorageFlags.Exportable | X509KeyStorageFlags.PersistKeySet | X509KeyStorageFlags.MachineKeySet)
Loads a certificate (with private key) directly from a PFX file on disk, with the same default flags as GetFromRawData, so the private key stays in the machine key store. The password may be null for a password-less PFX. A missing file or wrong password is returned as an ErrorType.Unexpected error rather than thrown.
Parameters
| Name | Type | Description |
|---|---|---|
certificateFile |
string |
Path to the .pfx file. |
password |
string? |
The PFX password, or null if the file is not password-protected. |
keyStorageFlags |
X509KeyStorageFlags |
The storage flags of the load, as in GetFromRawData. |
Example (a key in memory only)
ErrorOr<X509Certificate2> inMemory = CertificateFactory.GetFromFile(
"mycert.pfx", "S3cr3t!Passw0rd", X509KeyStorageFlags.EphemeralKeySet);
Example
ErrorOr<X509Certificate2> result = CertificateFactory.GetFromFile("mycert.pfx", "S3cr3t!Passw0rd");
result.Switch(
cert => Console.WriteLine($"Loaded {cert.Thumbprint}"),
errs => Console.WriteLine($"Could not load: {errs[0].Type}"));
CertificateAccess
public static class CertificateAccess
Accesses and manages certificates in the OS certificate store, and reads a certificate's Subject Alternative Names. All read methods open the store read-only; AddToStore/RemoveFromStore open it read-write.
| Member | Returns | Summary |
|---|---|---|
AddToStore(X509Certificate2, StoreName, StoreLocation) |
ErrorOr<Success> |
Add a certificate to a store. |
FindByThumbprint(StoreName, StoreLocation, string) |
ErrorOr<X509Certificate2> |
Find a certificate by thumbprint (or NotFound). |
GetAllFromStore(StoreName, StoreLocation) |
ErrorOr<IEnumerable<X509Certificate2>> |
Return every certificate in a store. |
FindByDnsNames(StoreName, StoreLocation, IEnumerable<string>) |
ErrorOr<IEnumerable<X509Certificate2>> |
Find certificates whose SANs contain all of the given DNS names. |
GetAlternateNames(X509Certificate2) |
ErrorOr<IEnumerable<string>> |
Read the IP-address and DNS-name SAN entries of a certificate. |
RemoveFromStore(string, StoreName, StoreLocation) |
ErrorOr<Success> |
Remove a certificate by thumbprint (no-op if absent). |
StoreName, StoreLocation come from System.Security.Cryptography.X509Certificates; Success comes from ErrorOr.
AddToStore
public static ErrorOr<Success> AddToStore(
X509Certificate2 certificate,
StoreName storeName,
StoreLocation storeLocation)
Opens the specified store for read-write and adds the certificate.
Example
ErrorOr<Success> result = CertificateAccess.AddToStore(
certificate,
StoreName.My, // the "Personal" store
StoreLocation.CurrentUser); // per-user — no admin rights required
if (result.IsError) Console.WriteLine(result.FirstError.Description);
⚠️ Writing to
StoreLocation.LocalMachinerequires administrator privileges.StoreLocation.CurrentUserdoes not.
FindByThumbprint
public static ErrorOr<X509Certificate2> FindByThumbprint(
StoreName storeName,
StoreLocation storeLocation,
string thumbprint)
Returns the certificate matching thumbprint, or an ErrorType.NotFound error if it is not present. The search is not restricted to valid certificates (expired/untrusted certificates are still returned).
Example
ErrorOr<X509Certificate2> result = CertificateAccess.FindByThumbprint(
StoreName.My,
StoreLocation.CurrentUser,
certificate.Thumbprint);
if (!result.IsError)
Console.WriteLine($"Found: {result.Value.Subject}");
else if (result.FirstError.Type == ErrorType.NotFound)
Console.WriteLine("No certificate with that thumbprint.");
GetAllFromStore
public static ErrorOr<IEnumerable<X509Certificate2>> GetAllFromStore(
StoreName storeName,
StoreLocation storeLocation)
Returns all certificates currently in the store as a materialised list.
Example
ErrorOr<IEnumerable<X509Certificate2>> result = CertificateAccess.GetAllFromStore(
StoreName.My,
StoreLocation.CurrentUser);
foreach (X509Certificate2 cert in result.Value)
Console.WriteLine($"{cert.Subject} ({cert.Thumbprint})");
FindByDnsNames
public static ErrorOr<IEnumerable<X509Certificate2>> FindByDnsNames(
StoreName storeName,
StoreLocation storeLocation,
IEnumerable<string> dnsEntries)
Returns every certificate in the store whose Subject Alternative Names contain all of the requested entries. Matching is case-insensitive. Because the comparison uses All, a certificate is returned only if it covers every name you pass.
Example
// Certificates that are valid for BOTH names:
ErrorOr<IEnumerable<X509Certificate2>> result = CertificateAccess.FindByDnsNames(
StoreName.My,
StoreLocation.CurrentUser,
new[] { "myapp.local", "api.myapp.local" });
foreach (X509Certificate2 cert in result.Value)
Console.WriteLine(cert.Thumbprint);
GetAlternateNames
public static ErrorOr<IEnumerable<string>> GetAlternateNames(X509Certificate2 certificate)
Reads the certificate's SAN extension and returns its IP-address entries (rendered via IPAddress.ToString()) followed by its DNS-name entries, each group in the extension's order; in a certificate of this package your custom entries come before the defaults. A certificate with no SAN extension yields a successful, empty sequence.
Example
ErrorOr<IEnumerable<string>> result = CertificateAccess.GetAlternateNames(certificate);
foreach (string name in result.Value)
Console.WriteLine(name);
// Output for a certificate created with the custom entry "myapp.local":
// 127.0.0.1
// ::1
// 0.0.0.0
// ::
// 0.0.0.0
// myapp.local
// localhost
// MACHINENAME
RemoveFromStore
public static ErrorOr<Success> RemoveFromStore(
string thumbprint,
StoreName storeName,
StoreLocation storeLocation)
Opens the store for read-write and removes the certificate identified by thumbprint. If no such certificate exists, the call is a harmless no-op that still reports success.
Example
ErrorOr<Success> result = CertificateAccess.RemoveFromStore(
certificate.Thumbprint,
StoreName.My,
StoreLocation.CurrentUser);
AesCryptography
public static class AesCryptography
Derives AES keys with PBKDF2 and encrypts strings into one of two payload formats:
- Authenticated (use this):
AesGcmEncryptwrites"v2:<iterations>:<base64 salt>:<base64 nonce>:<base64 ciphertext and tag>"with AES-256-GCM. The payload records its parameters, andAesGcmDecryptreports a wrong password or a changed payload as an error. - Legacy:
AesEncrypt(obsolete) writes"<base64 IV>:<base64 ciphertext>"with AES-CBC and no integrity protection.
AesDecrypt reads both, so data written in either format keeps decrypting.
| Member | Returns | Summary |
|---|---|---|
MakeAESKey(string, string, HashAlgorithmName?, int, int) |
ErrorOr<byte[]> |
Derive a key from a password + salt using PBKDF2. |
AesGcmEncrypt(string, string, int?) |
ErrorOr<string> |
Encrypt a string into the authenticated "v2:..." format. |
AesGcmDecrypt(string, string) |
ErrorOr<string> |
Decrypt a "v2:..." payload; an error on any failure. |
AesEncrypt(string, string, HashAlgorithmName?, int, int) |
ErrorOr<string> |
Obsolete. Encrypt a string into the legacy "iv:ciphertext" format. |
AesDecrypt(string, string, HashAlgorithmName?, int, int) |
ErrorOr<string> |
Decrypt a payload of either format; the input back on any failure. |
Iterations (constant) |
int |
100000: the default PBKDF2 iteration count of MakeAESKey and the legacy format. |
DefaultOutputLength (constant) |
int |
32: the default key length in bytes (AES-256) of MakeAESKey and the legacy format. |
Defaults of MakeAESKey, AesEncrypt and AesDecrypt: hashAlgorithmName = SHA-256, outputLength = DefaultOutputLength (32 bytes, AES-256), iterations = Iterations (100 000). Both are const, and optional-parameter defaults are compiled into the calling assembly: a different value in a later package version reaches your code only when you recompile.
The legacy payload does not record these parameters: decrypt it with the same hashAlgorithmName, outputLength and iterations you encrypted with.
Moving to the authenticated format. Encrypt new data with AesGcmEncrypt. Keep decrypting with AesDecrypt, which reads both formats, or switch to AesGcmDecrypt once every stored value is in the new format. To convert a stored value, decrypt it with AesDecrypt and encrypt the result with AesGcmEncrypt. A package version without AesGcmEncrypt cannot read the new format: its AesDecrypt returns such a payload unchanged.
MakeAESKey
public static ErrorOr<byte[]> MakeAESKey(
string password,
string salt,
HashAlgorithmName? hashAlgorithmName = null,
int outputLength = 32,
int iterations = 100000)
Derives a symmetric key from password and salt using PBKDF2. Deterministic: the same inputs always produce the same key. A null password or salt returns an ErrorType.Validation error whose Description names the offending parameter.
Parameters
| Name | Type | Description |
|---|---|---|
password |
string |
The secret to derive the key from. |
salt |
string |
The salt mixed into the derivation. |
hashAlgorithmName |
HashAlgorithmName? |
The PBKDF2 PRF. Defaults to SHA-256 when null. |
outputLength |
int |
Desired key length in bytes. Defaults to 32 (256-bit). |
iterations |
int |
PBKDF2 iteration count. Defaults to 100000. |
Example
ErrorOr<byte[]> key = AesCryptography.MakeAESKey("correct horse", "a-pinch-of-salt");
if (!key.IsError)
Console.WriteLine(key.Value.Length); // 32
// Validation error for a null password:
ErrorOr<byte[]> bad = AesCryptography.MakeAESKey(null!, "salt");
Console.WriteLine(bad.FirstError.Type); // Validation
Console.WriteLine(bad.FirstError.Description); // password
AesEncrypt
public static ErrorOr<string> AesEncrypt(
string password,
string content,
HashAlgorithmName? hashAlgorithmName = null,
int outputLength = 32,
int iterations = 100000)
⚠️ Obsolete. The payload is AES-CBC without integrity protection (see Security notes); use
AesGcmEncryptfor new data. A call raises warning CS0618, so a project that treats warnings as errors fails to build until it moves toAesGcmEncryptor suppresses the warning.AesDecryptkeeps reading whatAesEncryptwrote.
Encrypts content with an AES key derived from password (via MakeAESKey) and a fresh random IV, returning "<base64 IV>:<base64 ciphertext>".
nullpassword →ErrorType.Validation(Description = "password").null/empty/whitespace content → a successful empty string (nothing to encrypt).- The same content encrypted twice yields different payloads (random IV).
When using
AesEncrypt/AesDecrypt, keepoutputLengthat a valid AES key size —16,24or32bytes — because the derived key is assigned toAes.Key.
Example
ErrorOr<string> encrypted = AesCryptography.AesEncrypt("p@ssword", "Hello, world!");
Console.WriteLine(encrypted.Value); // e.g. "Q2hhbmdlSVZ...=:8f2bniH4...=="
AesDecrypt
public static ErrorOr<string> AesDecrypt(
string password,
string encryptedContent,
HashAlgorithmName? hashAlgorithmName = null,
int outputLength = 32,
int iterations = 100000)
Decrypts a payload of either format:
- a
"<base64 IV>:<base64 ciphertext>"string produced byAesEncrypt, using the same password and key-derivation parameters; - a
"v2:..."payload produced byAesGcmEncrypt(told apart by the prefixv2:), throughAesGcmDecrypt; the payload records its own parameters, sohashAlgorithmName,outputLengthanditerationsare ignored for it.
Failure handling is deliberately lenient — the only error path is a null password (ErrorType.Validation). For any non-null password:
- A correct password + valid payload → the original plaintext.
null/empty/whitespace input → a successful empty string.- Malformed input (not two colon-separated parts, and not a
v2:payload) → returned unchanged. - An undecodable payload (bad Base64, wrong lengths) → the original input is returned unchanged, thanks to the internal
.Else(...)fallback. - A
v2:payload thatAesGcmDecryptrejects (a wrong password, a changed or malformed payload) → returned unchanged. UseAesGcmDecryptitself to get the error. - A legacy payload with a wrong password → usually the original input unchanged: the derived key is wrong, the padding check fails, and the fallback returns the input. In about 0.4 % of the cases (measured: 300 in 80,000 tries) the wrong key still leaves valid padding, and other text comes back as a success. The plaintext is never disclosed, but a success does not prove that the password was right: the legacy payload has no integrity check (see Security notes).
Example
string payload = AesCryptography.AesEncrypt("p@ssword", "Hello, world!").Value;
// Correct password round-trips back to the plaintext:
ErrorOr<string> ok = AesCryptography.AesDecrypt("p@ssword", payload);
Console.WriteLine(ok.Value); // Hello, world!
// A wrong password never reveals the plaintext (it usually returns the input unchanged):
ErrorOr<string> wrong = AesCryptography.AesDecrypt("not-the-password", payload);
Console.WriteLine(wrong.Value == "Hello, world!"); // False
// The same call reads the authenticated format:
string v2 = AesCryptography.AesGcmEncrypt("p@ssword", "Hello, world!").Value;
Console.WriteLine(AesCryptography.AesDecrypt("p@ssword", v2).Value); // Hello, world!
AesGcmEncrypt
public static ErrorOr<string> AesGcmEncrypt(
string password,
string content,
int? iterations = null)
Encrypts content with AES-256-GCM into an authenticated payload:
v2:<iterations>:<base64 salt>:<base64 nonce>:<base64 ciphertext followed by the tag>
- The key is PBKDF2-HMAC-SHA256 of the UTF-8
passwordwith a random 16-byte salt (32 bytes); the nonce is random (12 bytes), the tag 16 bytes. - The version, the iteration count, the salt and the nonce are authenticated with the ciphertext (as associated data), so a change to any of them is detected.
iterationsis recorded in the payload: from1to6,000,000.nulltakes the library's current default, 600,000 (the OWASP figure for PBKDF2-HMAC-SHA256), applied at run time, so a later raise reaches your code without a recompile; existing payloads keep the count they were made with.- Empty and whitespace-only content is encrypted too, and comes back exactly.
- The same content encrypted twice yields different payloads (random salt and nonce).
Errors:
| Case | Error |
|---|---|
null password or content |
ErrorType.Validation, Description = the parameter's name |
iterations below 1 or above 6,000,000 |
ErrorType.Validation, Description = "iterations" |
The platform has no AES-GCM (AesGcm.IsSupported is false) |
ErrorType.Failure, Code = "AesGcm.NotSupported"; there is no fallback to the legacy format |
Every decryption runs PBKDF2 with the payload's iteration count: with the default, about 46 ms on a desktop Intel Core i9-14900KF; slower machines take longer.
Example
ErrorOr<string> encrypted = AesCryptography.AesGcmEncrypt("p@ssword", "Hello, world!");
Console.WriteLine(encrypted.Value); // e.g. "v2:600000:x6y+E1gT...==:KU8evXU1...:/878FRsu..."
AesGcmDecrypt
public static ErrorOr<string> AesGcmDecrypt(string password, string encryptedContent)
Decrypts a payload of AesGcmEncrypt. Unlike AesDecrypt, it reports every failure as an error, and never returns text for a wrong password or a changed payload:
| Case | Error |
|---|---|
null password or payload |
ErrorType.Validation, Description = the parameter's name |
Not a valid payload: not the v2: format, Base64 or lengths that do not fit, or an iteration count outside 1 to 6,000,000 (checked before the key is derived, so a payload cannot make a decryption run longer) |
ErrorType.Validation, Code = "AesGcm.InvalidPayload" |
| A wrong password, or a changed payload | ErrorType.Failure, Code = "AesGcm.AuthenticationFailed" |
| The platform has no AES-GCM | ErrorType.Failure, Code = "AesGcm.NotSupported" |
No error carries the password, the key or any part of the plaintext.
Example
string payload = AesCryptography.AesGcmEncrypt("p@ssword", "Hello, world!").Value;
ErrorOr<string> ok = AesCryptography.AesGcmDecrypt("p@ssword", payload);
Console.WriteLine(ok.Value); // Hello, world!
ErrorOr<string> wrong = AesCryptography.AesGcmDecrypt("not-the-password", payload);
Console.WriteLine(wrong.FirstError.Code); // AesGcm.AuthenticationFailed
How Subject Alternative Names are built
When you call either CreateSelfSigned overload (and therefore GetForLocalhost), the SAN extension is assembled as follows:
- Your custom entries (
dnsNames) are processed one by one:- A value that parses as an IP address is added as an IP SAN — unless it is a loopback address (
127.0.0.1/::1), which is skipped because it is added by default below. - The reserved names
localhost,*, and the current machine name are skipped (also added by default below). - Anything else is added as a DNS name.
- A value that parses as an IP address is added as an IP SAN — unless it is a loopback address (
- A fixed set of default entries is always appended:
- IP addresses:
127.0.0.1,::1,0.0.0.0,::, and0.0.0.0again (IPAddress.Any), so0.0.0.0appears twice. - DNS names:
localhostand the current machine name.
- IP addresses:
The net effect: every generated certificate is automatically valid for loopback, "any" addresses, localhost and the local machine. The skip rules keep your copies of 127.0.0.1, ::1, localhost, * and the machine name out of the list; 0.0.0.0 and :: are not skipped, so passing them adds them once more.
End-to-end example
Create a certificate, persist it to a store, retrieve it, then clean up:
using System.Security.Cryptography.X509Certificates;
using ErrorOr;
using Forge.Next.Security;
// 1. Create a self-signed certificate valid for an internal host name.
ErrorOr<X509Certificate2> created = CertificateFactory.CreateSelfSigned(
x500: "CN=Orders Service",
friendlyName: "Orders Service TLS",
dnsNames: new[] { "orders.internal", "10.0.0.20" },
startTime: DateTime.UtcNow.AddDays(-1),
endTime: DateTime.UtcNow.AddYears(3));
if (created.IsError)
return;
X509Certificate2 certificate = created.Value;
// 2. Persist it to the current user's personal store (no admin rights needed).
CertificateAccess.AddToStore(certificate, StoreName.My, StoreLocation.CurrentUser);
try
{
// 3. Later, retrieve it by thumbprint...
ErrorOr<X509Certificate2> loaded = CertificateAccess.FindByThumbprint(
StoreName.My, StoreLocation.CurrentUser, certificate.Thumbprint);
// ...or by the names it must cover.
ErrorOr<IEnumerable<X509Certificate2>> byDns = CertificateAccess.FindByDnsNames(
StoreName.My, StoreLocation.CurrentUser, new[] { "orders.internal" });
// 4. Inspect what it is valid for.
foreach (string san in CertificateAccess.GetAlternateNames(loaded.Value).Value)
Console.WriteLine(san);
// 5. Back it up to a password-protected PFX for safe keeping.
ErrorOr<byte[]> pfx = CertificateFactory.ExportToPfxRawData(loaded.Value, "Backup#2024");
if (!pfx.IsError)
File.WriteAllBytes("orders-service.pfx", pfx.Value);
}
finally
{
// 6. Clean up the store entry when you are done.
CertificateAccess.RemoveFromStore(
certificate.Thumbprint, StoreName.My, StoreLocation.CurrentUser);
}
Using a certificate to host HTTPS with Kestrel:
var builder = WebApplication.CreateBuilder(args);
builder.WebHost.ConfigureKestrel(options =>
{
options.ListenLocalhost(5001, listen =>
{
ErrorOr<X509Certificate2> cert = CertificateFactory.GetForLocalhost("CN=localhost", "Dev HTTPS");
listen.UseHttps(cert.Value);
});
});
var app = builder.Build();
app.MapGet("/", () => "Hello over HTTPS!");
app.Run();
Encrypting and decrypting a secret:
string token = AesCryptography.AesGcmEncrypt("master-password", "api-key-12345").Value;
ErrorOr<string> back = AesCryptography.AesGcmDecrypt("master-password", token);
Console.WriteLine(back.IsError ? back.FirstError.Code : back.Value); // api-key-12345
Notes, gotchas & platform behaviour
Exception-free: expected failures are returned as
ErrorOrerrors, not thrown. Always checkIsError(or useMatch/Switch) before reading.Value.Friendly names are Windows-only.
friendlyNameis applied only when running on Windows; on Linux/macOS the property is left empty (the certificate is otherwise identical).MachineKeySetmay require elevation, and the keys stay. The password-basedCreateSelfSigned,GetFromRawDataandGetFromFileimport keys, by default, withExportable | PersistKeySet | MachineKeySet; passkeyStorageFlags: X509KeyStorageFlags.EphemeralKeySetwhere an in-memory key is enough (not for a TLS server on Windows, not on macOS). On Windows this writes the private key to the machine key store (a file inC:\ProgramData\Microsoft\Crypto\Keys) and usually needs administrator rights; failures surface asErrorType.Unexpected. The key file stays there after the certificate is disposed: every call adds one, and nothing in this package removes it. When you no longer need a key, and no certificate in a store still uses it, delete it yourself:using RSA? rsa = certificate.GetRSAPrivateKey(); if (OperatingSystem.IsWindows() && rsa is RSACng cng) cng.Key.Delete(); // removes the key file; the certificate can no longer use its private keynet8.0also loads DER files. Onnet8.0,GetFromRawDataandGetFromFilealso accept a DER certificate (a.cer) and return it without a private key; fromnet9.0they accept PKCS#12/PFX only and return anErrorType.Unexpectederror for DER.Store write permissions.
AddToStore/RemoveFromStoreagainstStoreLocation.CurrentUserwork without elevation;StoreLocation.LocalMachinerequires administrator rights.Validity precision. X.509 stores
NotBefore/NotAfterwith whole-second precision, so sub-second parts of yourDateTimearguments are truncated.X509Certificate2.NotBefore/NotAfterare returned in local time. Convert with.ToUniversalTime()before comparing against UTC values.AES key size. Through
AesEncrypt/AesDecrypt(the legacy format),outputLengthmust be16,24or32bytes (the derived key becomesAes.Key).MakeAESKeyon its own accepts any length.AesDecryptis lenient by design. With a non-null password it never returns an error: a malformed payload, and almost every wrong password, yields the input unchanged rather than an exception, so it never leaks the plaintext but also will not tell you decryption "failed". For a legacy payload, comparing the result against the input catches most failures, not all: about 0.4 % of wrong passwords give other text (seeAesDecrypt). To get an error instead, use the authenticated format andAesGcmDecrypt.Disposal.
X509Certificate2isIDisposable. Dispose certificates you no longer need (e.g. with ausingstatement) to release key material promptly.
Security notes
Use the authenticated AES format. A payload of
AesGcmEncryptis AES-256-GCM: a wrong password or any change to the payload fails authentication, andAesGcmDecryptreports it as an error. Its decryption accepts at most 6,000,000 PBKDF2 iterations and checks the count before deriving the key, so a crafted payload cannot make it run for long.The legacy AES payload has no integrity protection.
AesEncrypt(obsolete) uses AES-CBC without a MAC, andAesDecryptchecks none for that format:- a changed payload can decrypt to changed text as a success (in a test, one flipped ciphertext bit changed one character of the next block);
- a wrong password gives other text as a success in about 0.4 % of the cases (see
AesDecrypt); AesDecryptanswers differently to a bad padding (the input back) and a good one (other text), so do not let an untrusted party submit payloads to it and see the result: that makes a padding oracle possible.
Move such data to
AesGcmEncrypt(seeAesCryptography); until then keep the payloads where others cannot change them.The PFX export's work factor is low.
ExportToPfxRawDataprotects the PFX with AES-256 onnet10.0and later, and with the legacy TripleDES and SHA-1 onnet8.0andnet9.0(seeExportToPfxRawData); either way the password is stretched with only 2,000 iterations. A PFX with a weak password is cheap to attack offline: give a PFX you keep a long random password, and store it where others cannot read it.Errors carry stack traces. Every
ErrorType.Unexpectederror carries the exception'stype,messageandstackTracein itsMetadata. Before you send an error out of your process (an HTTP response, a message to another service), remove the metadata, or at least thestackTrace.No secrets in this package's own errors. The package logs nothing, and its
Validationerrors name the parameter, never its value.
Testing
The repository contains an xUnit test suite under tests/Forge.Next.Security.Tests (xUnit + Shouldly + NSubstitute) that exercises the full public surface of all three classes on every target framework (net8.0 to net11.0, so the four runtimes are needed). The PFX tests import keys with MachineKeySet (run them elevated on Windows) and delete the keys they create. Run it with:
dotnet test
License
Licensed under the Apache-2.0 License. See the license for details.
Authored by Zoltan Juhasz — part of the Forge Patterns and Practices family.
| Product | Versions Compatible and additional computed target framework versions. |
|---|---|
| .NET | net8.0 is compatible. net8.0-android was computed. net8.0-browser was computed. net8.0-ios was computed. net8.0-maccatalyst was computed. net8.0-macos was computed. net8.0-tvos was computed. net8.0-windows was computed. net9.0 is compatible. net9.0-android was computed. net9.0-browser was computed. net9.0-ios was computed. net9.0-maccatalyst was computed. net9.0-macos was computed. net9.0-tvos was computed. net9.0-windows was computed. net10.0 is compatible. net10.0-android was computed. net10.0-browser was computed. net10.0-ios was computed. net10.0-maccatalyst was computed. net10.0-macos was computed. net10.0-tvos was computed. net10.0-windows was computed. net11.0 is compatible. |
-
net10.0
- Forge.Next.Shared (>= 3.3.2)
-
net11.0
- Forge.Next.Shared (>= 3.3.2)
-
net8.0
- Forge.Next.Shared (>= 3.3.2)
-
net9.0
- Forge.Next.Shared (>= 3.3.2)
NuGet packages
This package is not used by any NuGet packages.
GitHub repositories
This package is not used by any popular GitHub repositories.
