FlappyBrain QuickStart Guide
FlappyBrain is a lightweight neural network library designed for genetic algorithms, particularly suitable for AI in games like Flappy Bird. This guide will help you get started with the library.
Installation
Install the FlappyBrain package via NuGet:
dotnet add package NeuralFlapper
Or via the NuGet Package Manager Console:
Install-Package NeuralFlapper
Basic Usage
Creating a Neural Network
using FlappyBrain.Library;
// Create a neural network with:
// - 3 input nodes
// - 4 hidden nodes
// - 2 output nodes
// - Sigmoid activation function
var network = new FlappyBrainNetwork(
inputNodes: 3,
hiddenNodes: 4,
outputNodes: 2,
activationFunction: ActivationFunction.Sigmoid
);
Processing Inputs
// Create an array of inputs
double[] inputs = new double[] { 0.5, 0.3, 0.9 };
// Calculate outputs
double[] outputs = network.CalculateWeights(inputs);
// Use the outputs
Console.WriteLine($"Output 1: {outputs[0]}");
Console.WriteLine($"Output 2: {outputs[1]}");
Activation Functions
FlappyBrain supports multiple activation functions:
ActivationFunction.Sigmoid
- Standard sigmoid function: f(x) = 1/(1+e^(-x))ActivationFunction.ReLU
- Rectified Linear Unit: f(x) = max(0, x)ActivationFunction.LeakyReLU
- Leaky ReLU: f(x) = x if x > 0, otherwise 0.01xActivationFunction.Tanh
- Hyperbolic tangent: f(x) = tanh(x)
// Example with ReLU activation function
var reluNetwork = new FlappyBrainNetwork(
inputNodes: 3,
hiddenNodes: 4,
outputNodes: 2,
activationFunction: ActivationFunction.ReLU
);
Network Architecture
FlappyBrain implements a classic three-layer neural network:
- Input layer: Accepts your input values
- Hidden layer: Processes the inputs through weighted connections
- Output layer: Produces the final output values
The network uses matrix operations for efficient calculations.
Accessing Network Properties
// Get the number of nodes in each layer
int inputs = network.InputNodes;
int hidden = network.HiddenNodes;
int outputs = network.OutputNodes;
// Get the activation function used
ActivationFunction activation = network.ActivationFunction;
// Access the weight matrices (advanced usage)
var weightLayers = network.Layers;
var inputToHiddenWeights = weightLayers[0];
var hiddenToOutputWeights = weightLayers[1];
Example: Building a Simple AI Agent
using FlappyBrain.Library;
// Create a neural network for a simple game AI
var aiAgent = new FlappyBrainNetwork(
inputNodes: 4, // For example: player position x,y and target position x,y
hiddenNodes: 6,
outputNodes: 2, // For example: move direction x,y
activationFunction: ActivationFunction.Tanh // Range from -1 to 1, good for movement
);
// In your game loop:
void Update()
{
// Gather sensor data
double[] sensorInputs = new double[] {
playerX / mapWidth, // Normalize to 0-1 range
playerY / mapHeight,
targetX / mapWidth,
targetY / mapHeight
};
// Get agent's decision
double[] decision = aiAgent.CalculateWeights(sensorInputs);
// Apply movement (tanh output gives -1 to 1 range)
float moveX = (float)decision[0];
float moveY = (float)decision[1];
// Move your agent accordingly
MoveAgent(moveX, moveY);
}
Notes for Genetic Algorithms
FlappyBrain is designed with genetic algorithms in mind. Here's a brief overview of how you might use it:
- Create a population of networks
- Evaluate each network's fitness based on performance
- Select the best networks for reproduction
- Apply mutation and crossover to create a new generation
While FlappyBrain doesn't include built-in genetic algorithm functions, its design makes it easy to implement your own genetic approach.
Support
For issues or questions, visit the GitHub repository: https://github.com/shinymajesty/flappybrain
