CrawlSharp 1.1.0

<img src="https://raw.githubusercontent.com/jchristn/CrawlSharp/refs/heads/main/assets/icon.png" width="256" height="256">

CrawlSharp

CrawlSharp is a library and integrated webserver for crawling basic web content.

New in v1.1.0

• Redirects are followed by CrawlSharp itself, one hop at a time: a redirect loop ends after one pass instead of hanging the crawl, and chains stop at MaxRedirects (default 10)
• Credentials are sent only to the start URL's origin (plus its HTTPS version and any Authentication.CredentialOrigins), are re-attached to same-origin redirect targets, and never reach another origin
• WebResource gains FinalUrl, RedirectChain and RedirectOutcome, and links on a redirected page resolve against its final URL
• Incomplete or ambiguous Authentication settings throw from the WebCrawler constructor, and the server answers 400
• FollowRedirects = false now returns the redirect response itself; see Upgrading to 1.1.0

Bugs, Feedback, or Enhancement Requests

Please feel free to start an issue or a discussion!

Simple Example, Embedded

Embedding CrawlSharp into your application is simple and requires minimal configuration. Refer to the Test project for a full example.

using System.Collections.Generic;
using CrawlSharp.Web;

Settings settings = new Settings();
settings.Crawl.StartUrl = "http://www.mywebpage.com";
settings.Crawl.UseHeadlessBrowser = true; // slow but useful for sites that block bots or where content must be rendered

using (WebCrawler crawler = new WebCrawler(settings))
{
  await foreach (WebResource resource in crawler.CrawlAsync())
    Console.WriteLine(resource.Status + ": " + resource.Url);
}

WebCrawler.CrawlAsync can be awaited, returning an IAsyncEnumerable<WebResource> whereas WebCrawler.Crawl cannot be awaited, returning an IEnumerable<WebResource>.

Opt-in auto-expansion can be enabled for headless crawls when you need CrawlSharp to open common collapsible UI patterns before HTML capture:

using CrawlSharp.Web;

Settings settings = new Settings();
settings.Crawl.StartUrl = "https://www.mywebpage.com";
settings.Crawl.UseHeadlessBrowser = true;
settings.Crawl.AutoExpandCollapsibles = true;
settings.Crawl.PostLoadDelayMs = 500;
settings.Crawl.ExpansionSelectors = new List<string>
{
  ".faq-toggle"
};

using (WebCrawler crawler = new WebCrawler(settings))
{
  await foreach (WebResource resource in crawler.CrawlAsync())
    Console.WriteLine(resource.Status + ": " + resource.Url);
}

Crawl Settings

Rendered HTML in Headless Mode

When UseHeadlessBrowser is enabled for navigable pages, CrawlSharp captures the rendered DOM HTML from Playwright and stores it in WebResource.Data.

When headless crawling is not used, CrawlSharp returns the server response bytes directly. For non-navigable assets such as PDFs, CrawlSharp also uses direct HTTP retrieval even when headless crawling is enabled.

Headless Auto-Expand

AutoExpandCollapsibles is disabled by default. Enable it when a page only inserts usable content into the DOM after a collapsible control is opened.

When enabled in headless mode, CrawlSharp will:

• Open closed <details> elements
• Click a conservative set of common collapsible controls such as ARIA-backed toggles and Bootstrap collapse buttons
• Apply any additional selectors supplied through ExpansionSelectors

Use PostLoadDelayMs when a page hydrates UI after the browser load event. Use PostInteractionDelayMs and MaxExpansionPasses to give nested lazy content time to appear between expansion passes.

ExpansionSelectors should stay narrow. Over-broad selectors can trigger unintended clicks and change the captured output.

Retry on 429 (Too Many Requests)

When RetryOn429 is enabled, the crawler will automatically retry individual page retrievals that receive a 429 status code. Retries use exponential backoff: the delay for each attempt is calculated as RetryMinBackoffMs * 2^attempt, capped at RetryMaxBackoffMs. When RetryBackoffJitter is enabled, the actual delay is randomized between 0 and the computed value to avoid synchronized retries across parallel tasks.

If all retry attempts are exhausted and the server still returns 429, the crawler falls back to the ThrottleMs delay and returns the 429 response as the result for that URL.

Pacing

Two settings control delays, and they do different jobs:

To crawl politely, tune RequestDelayMs and MaxParallelTasks together. ThrottleMs only matters once a server has started refusing requests.

Redirects

CrawlSharp follows redirects itself rather than letting the HTTP stack do it, so every hop gets the same checks:

• Hop limit: at most MaxRedirects redirects (default 10) are followed per resource. A longer chain stops with RedirectOutcome = MaxRedirectsExceeded, and the hop past the limit is not requested.
• Loop detection: when a chain returns to a URL it already requested (with the same cookies), it stops with LoopDetected. An A to B to A loop requests each URL once, and the rest of the crawl carries on.
• Cookies: cookies set by one hop are sent on the next hop of the same chain, so a consent wall or session bootstrap that sets a cookie and redirects back works. Cookies are not shared between pages.
• Scope: when FollowLinks is true, a redirect target must pass the same filters as a link (RestrictToChildUrls, RestrictToSameSubdomain, RestrictToSameRootDomain, AllowedDomains, DeniedDomains, FollowExternalLinks, ExcludeLinkPatterns); one that does not is not requested and the result has OutOfScope. robots.txt and sitemap.xml redirects are followed only on the start URL's host.
• robots.txt: a redirect to a disallowed path is not requested (RobotsDisallowed).
• Credentials are attached per hop according to the credential scope.
• Pacing: RequestDelayMs applies before each hop.

The resource that comes back always describes what happened. Url is the requested address, FinalUrl is where the content came from, RedirectChain lists each redirect, and RedirectOutcome is one of:

For every outcome other than None and Followed, Status and Data come from the last redirect response, not from page content, and links in that body are not followed.

Only 301, 302, 303, 307 and 308 are redirects, plus 300 when it carries a Location; 304 Not Modified is returned as-is. Links on a redirected page resolve against FinalUrl, so /docs redirecting to /docs/ resolves guide.html to /docs/guide.html. When two URLs redirect to the same page, the page is fetched and returned once.

Configure the canonical start URL. If https://example.com redirects to https://www.example.com and RestrictToSameSubdomain is on, the start page comes back as OutOfScope, and its RedirectChain shows the address to use instead.

When UseHeadlessBrowser is enabled, CrawlSharp resolves the chain with a HEAD request before starting the browser, then navigates straight to the final URL, so the same limits apply. A page that redirects differently on GET is resolved again with GET before navigating.

Authentication

Set Settings.Authentication to crawl a site that needs credentials:

Settings settings = new Settings();
settings.Crawl.StartUrl = "https://intranet.example.com";
settings.Authentication = new AuthenticationSettings
{
  Type = AuthenticationTypeEnum.Basic,
  Username = "crawler",
  Password = "secret"
};

Validation. The WebCrawler constructor calls AuthenticationSettings.Validate() and throws ArgumentException when the settings are incomplete or ambiguous: credential fields set while Type is None, a missing required field, or an invalid CredentialOrigins entry. Empty and whitespace strings count as unset. The REST server returns these as 400 Bad Request.

Credential scope. Credentials are sent only to requests whose origin (scheme, host and port) is one of:

• the origin of StartUrl
• when StartUrl is plain HTTP, the HTTPS origin on the same host (the common HTTP to HTTPS upgrade)
• any origin listed in Authentication.CredentialOrigins, for sites that span several origins, for example "https://docs.example.com"

The rule applies per request and per redirect hop, for the REST client and the headless browser alike. A same-origin redirect target gets credentials; a redirect or link to another origin never does, and an HTTPS start URL never sends credentials to an HTTP downgrade.

Upgrading to 1.1.0

• FollowRedirects = false is now literal. In 1.0.22 the HTTP stack followed redirects regardless of this setting, so false still returned the final page. It now returns the redirect response (usually an empty 3xx) with RedirectOutcome = NotFollowed. If you set false to avoid the redirect-loop hang, set it back to true (the default): loops are now detected.
• Credentials stay on their origin. 1.0.22 attached credentials to every request, including external links and other origins reached by redirects. An authenticated crawl that spans several origins now needs those origins in Authentication.CredentialOrigins.
• Authentication settings are validated. Credentials with Type = None, which were silently ignored, now throw. So does an incomplete configuration such as Type = ApiKey without ApiKeyHeader, which used to produce an empty crawl.
• 304, 305 and 306 are no longer treated as redirects.
• Url is the requested address. Read FinalUrl for the address the content came from.

Web Resources

Objects crawled using CrawlSharp have the following properties:

• Url - the URL that was requested
• FinalUrl - the URL the content in Data came from; equal to Url when there was no redirect
• RedirectChain - the redirects received, in order, each with Url, Status and Location; empty when there was no redirect
• RedirectOutcome - why redirect following stopped; see Redirects
• ParentUrl - the URL from which the Url was identified
• Filename - the filename component from the URL, if any
• Depth - the depth level at which the Url was identified
• Status - the HTTP status code returned when retrieving the Url
• ContentLength - the content length of the body returned when retrieving Url
• ContentType - the content type returned while retrieving Url
• MD5Hash - the MD5 hash of the Data
• SHA1Hash - the SHA1 hash of the Data
• SHA256Hash - the SHA256 hash of the Data
• LastModified - the DateTime from when the headers indicate the object was last modified
• Headers - a NameValueCollection with the headers returned while retrieving Url
• Data - a byte[] containing the data returned while retrieving Url

REST API

CrawlSharp includes a project called CrawlSharp.Server which allows you to deploy a RESTful front-end for CrawlSharp. Refer to REST_API.md and also the Postman collection in the root of this repository for details.

CrawlSharp.Server will by default listen on host localhost and port 8000, meaning it will not accept requests from outside of the machine.

To change this, specify the hostname as the first argument and the port as the second, i.e. dotnet CrawlSharp.Server myhostname.com 8888.

$ dotnet CrawlSharp.Server

                          _     _  _
   ___ _ __ __ ___      _| |  _| || |_
  / __| '__/ _` \ \ /\ / / | |_  ..  _|
 | (__| | | (_| |\ V  V /| | |_      _|
  \___|_|  \__,_| \_/\_/ |_|   |_||_|

(c)2026 Joel Christner


Usage:
  crawlsharp [hostname] [port]

Where:
  [hostname] is the hostname or IP address on which to listen
  [port] is the port number, greater than or equal to zero, and less than 65536

NOTICE
------
Configured to listen on local address 'localhost'
Service will not receive requests from outside of localhost

Webserver started on http://localhost:8000/

2025-03-01 20:39:17 joel-laptop Info [CrawlSharpServer] server started

Refer to REST_API.md for more information about using the RESTful API.

Dashboard

CrawlSharp includes a web-based dashboard for configuring, launching, and monitoring crawls through your browser. The dashboard is a React (Vite) application located in the dashboard/ directory.

Features

• Server selector - switch the dashboard between proxy, localhost, and custom server endpoints from the top-right toolbar

• New Crawl - configure all crawl and authentication settings through the UI and launch a crawl against the CrawlSharp server

• Active Crawl - monitor a running crawl in real time with a live feed of discovered resources, status code distribution, and content type breakdown

• Crawl History - view past crawl results, including per-page status, content types, sizes, and hashes

• Templates - save, duplicate, and reuse crawl configurations for repeated jobs

Running the Dashboard Locally

Prerequisites: Node.js (v18 or later).

cd dashboard
npm install
npm run dev

The dashboard will start on http://localhost:8001 and expects the CrawlSharp server to be running on http://localhost:8000. The Vite dev server proxies /crawl requests to the server automatically.

Building for Production

cd dashboard
npm run build

The compiled output is written to dashboard/dist/ and can be served by any static file server.

Configuring the Server URL

The dashboard determines the CrawlSharp server URL in the following order of precedence:

Use the top-right server endpoint icon in the dashboard toolbar to change the active endpoint without editing local storage by hand.

1. localStorage - the value saved at key crawlsharp_server_url (set through the dashboard UI)
2. Runtime config - the CRAWLSHARP_SERVER_URL value in public/config.js, which is overridden at container startup when running in Docker
3. Default - http://localhost:8000

Running with Docker Compose

The easiest way to run both the server and dashboard together is with Docker Compose. The Docker/compose.yaml includes both the crawlsharp-server and crawlsharp-ui services. The dashboard container uses nginx to reverse-proxy API requests to the CrawlSharp server internally, so no direct browser-to-server connectivity is needed.

The CRAWLSHARP_SERVER_URL environment variable controls the server URL used by the dashboard. When left empty (the default in Docker Compose), the dashboard routes API requests through its own nginx proxy. When running the dashboard outside of Docker, set it to the server's URL (e.g. http://localhost:8000).

To start both services:

cd Docker
docker compose up -d

The server is available at http://localhost:8000 and the dashboard at http://localhost:8001.

Use docker compose down (or the provided compose-down scripts) to stop.

Running in Docker

A Docker image is available in Docker Hub under jchristn77/crawlsharp. Use the Docker Compose start (compose-up.sh and compose-up.bat) and stop (compose-down.sh and compose-down.bat) scripts in the Docker directory if you wish to run within Docker Compose.

Using Headless Browser

CrawlSharp can use Microsoft.Playwright to crawl content to overcome challenging websites that detect and block bots or require content to be rendered from Javascript. If you run this code on an Ubuntu machine, use the following script to install dependencies that will be required. Also note that the $HOME directory must be owned by the user running the code.

#!/bin/bash

# Detect Ubuntu version
VERSION=$(lsb_release -rs)

if [[ "$VERSION" == "24.04" ]]; then
    # Ubuntu 24.04 packages
    PACKAGES="libasound2t64 libatk-bridge2.0-0t64 libatk1.0-0t64 libcups2t64 libgtk-3-0t64"
else
    # Ubuntu 22.04 and earlier
    PACKAGES="libasound2 libatk-bridge2.0-0 libatk1.0-0 libcups2 libgtk-3-0"
fi

# Install common packages plus version-specific ones
sudo apt-get update
sudo apt-get install -y \
    $PACKAGES \
    libnspr4 \
    libnss3 \
    libdrm2 \
    libxkbcommon0 \
    libxcomposite1 \
    libxdamage1 \
    libxrandr2 \
    libgbm1 \
    libxss1 \
    fonts-liberation \
    ca-certificates

Third-Party Data

CrawlSharp is licensed under MIT and uses the Nager.PublicSuffix library (MIT license) for domain matching coupled with third-party public suffix data (Mozilla Public License v2.0). Please be aware of the license for this information.

Version History

Please refer to CHANGELOG.md for version history.
